Reference : SGP_AVS_SW_ATLAS-05-05 Classification : COMPANY RESTRICTED
Version : 0.17 Project : ATLAS_DSW
Status : Proposed Chapter : User Manual
Date : 2006-09-12
Section : Diagnostic Software (Leco+)
© Philips Electronics N.V. 2006 Philips Semiconductors Page 29 of 124
euro 11
Scenario : Timer Recording (Analog TV Tuner) and
loopthrough (scart1 to scart2 and scart2 to scart1)
scart1 to scart2 cvbs and audio loopthrough,
scart2 to scart1 cvbs and audio loopthrough,
tuner cvbs and audio in,
rear cvbs and audio out
euro 12
Scenario : Watching analog TV tuner and output
Leco+ CVBS to scart 1 and loop CVBS
from scart 1 to scart 2
(decoder set to OFF in recorder UI)
tuner cvbs in
rear cvbs and rear rgb out
scart1 cvbs, rgb and audio out
scart1 to scart2 cvbs and audio loopthrough,
euro 13
Scenario: SPDIF audio recording
spdif rear out,
spdif rear in.
euro 14
Scenario:
Standby Loopthru (scart1 to scart2)
scart1 to scart2 cvbs and audio loopthrough,
euro 15
Scenario:
Watching DTT and output Leco+ CVBS to
scart 1 and loop CVBS from scart 1 to scart 2
DTT cvbs and audio in
rear cvbs and audio out
scart1 cvbs and audio out
scart1 to scart2 cvbs and audio loopthrough,
euro 16
Scenario :
Recording from DTT and watching the output on scart1, scart2
DTT cvbs and audio in
scart1 cvbs and audio out.
scart2 cvbs and audio out,
euro 17
Scenario:
Recording from DTT in the background
and loopthrough (scart1 to scart2 and scart2 to scart1)
DTT cvbs and audio in
scart1 to scart2 cvbs and audio loopthrough.
scart2 to scart1 cvbs and audio loopthrough.
rear cvbs and audio out, rear spdif out
euro 18
Scenario: Decoder Mode (Transition after Scart 2 pin 8 raised)
tuner cvbs and audio in
scart2 cvbs and audio out and then in.
scart1 cvbs and audio out,
rear cvbs, rgb and audio out
euro 19
Scenario: Decoder Mode passive loop through
scart2 to scart 1 rgb loopthrough.
tuner cvbs and audio in.
scart2 cvbs and audio out and then in.
scart1 cvbs and audio out,
euro 20
SCART2 audio input to external audio ADC
scart2 rgb and audio in,
scart1 rgb and audio out(via external audio ADC).
euro 21 SCART1 audio input to external audio ADC
