ErgoLine D330/D340
Customer Engineer Manual
Page 2-38
S8 Not used Pause Duration for Dial Delay. Not
supported. Default is ASCII 1
S9 Not used Reaction Time to Received Carrier.
Default is ASCII 6
S10 Not used Time Delay from Loss of Carrier to
Clearing of Connection. The synchronisation
may be lost for up to 3 seconds.
Default is ASCII 7
S11 Not used Duration and Interval of the MFV-
Tone. Default is ASCII 70
S12 Maximum Supervision Time for an escape
sequence. Default is 0.5 seconds (the time is
given in hundredths of a second)
Note: S6 to S11 are not applicable to ISDN/Digital terminals
T
ABLE
2-15. R
ESULT
C
ODES
N
OT ALL OF THE
H
AYES
R
ESULT
C
ODES ARE USED
. R
ESULT
C
ODES ARE SENT AS REACTIONS TO COMMANDS
OR MESSAGES FROM THE
S
WITCH
. I
F AND WHEN THE
R
ESULT
C
ODES ARE EXPRESSED DEPENDS UPON THE
APPLIED
V
COMMANDS
(V0 & V1)
AND THE
X
COMMANDS
(X0, X1 & X3).
0 OK Command executed
1 CONNECT Connected at 0 .. 300 bit/s
2 RING Incoming call
3 NO CARRIER No synchronisation or synchronisation lost
4 ERROR Error in given command
5 CONNECT 1200 Connected at 1200 bit/s
7 BUSY Busy
10 CONNECT 2400 Connected at 2400 bit/s
11 CONNECT 4800 Connected at 4800 bit/s
12 CONNECT 9600 Connected at 9600 bit/s
13 CONNECT>xxxx Connected at xxxx bit/s (over 9600 bit/s)
