Page 103 E
VERFLO
TM
SERVICE & TECHNICAL INFORMATION 1039055, VER. 06
Alarm
Oxygen purity reported by the internal OPI sensor. OPI devices only.
OPI sensor remains on as long as the device is turned on.
Firmware version of the MSP microcontroller: Currently released manufacturing
firmware is 3.0 and will show as 30 in the MSP version box. 4.2 will show as 42 in the
version box.
Oxygen sensor heater power gauge
The device computed flow from the PCA.
This field is now enabled to input hours from the device hour meter. Used to transfer
the hours from the analog hour meter into the LCD hour meter.
11.1.5 EverFlo Service Tool information:
Definitions Of The Lower Check Box Section
TRUE if a silent restart is in progress.
TRUE if AC mains frequency detection reports 60 Hz.
TRUE if O2 sensor output is considered valid.
TRUE if the O2 sensor bias is enabled.
TRUE if high flow alarm condition is active
TRUE if the EverFlo is TransFill Enabled and actively
supplying a TransFill device.
11.1.6 Table for the Device Alarms Box:
Definitions Of The Higher Check Box Section: Alarms
If checked, the memory consistency check of the parameter memory has failed.
If checked, product canister pressure has remained below the low pressure threshold.
If checked, product canister pressure has remained above the high pressure threshold.
If checked, product O2 purity has remained below the Very low O2 threshold. Red light
alarm
If checked, product O2 purity has remained above the High O2 threshold and the O2
Sensor has stopped working.
If checked, product O2 purity has remained below the low O2 threshold, but above the
Very Low O2 threshold.
If checked, output flow has been determined to be at or near zero flow.
If checked, a power on self-test failure occurred.
Checked, when the elapsed hour indicator discrete output is being pulsed.
Active when the audible alarm discrete output is driven active.
