Service Modes, Error Codes and Fault Finding
EN 21FM24 5.
5.5.2 How to Clear the Error Buffer
The error code buffer is cleared in the following cases:
• By activation of the 'Reset error buffer' command in the
SAM menu.
• When you transmit the code 0 6 2 5 9 9 with a standard
remote control transmitter.
5.5.3 Error Codes
Table 5-1 Error code overview
Notes:
• In case of non-intermittent faults, clear the error buffer
before you begin the repair. This to ensure that old error
codes are no longer present.
• If possible, check the entire contents of the error buffer. In
some situations, an error code is only the result of another
error code and not the actual cause (e.g., a fault in the
protection detection circuitry can also lead to a protection).
5.6 The Blinking LED Procedure
Via this procedure, you can make the contents of the error
buffer visible via the front LED (orange colour).This is
especially useful when there is no picture. When no errors are
present, the LED will stay green.
When the SDM is entered, or when code 0 6 2 5 0 0 is entered
with the remote control, the LED will blink the contents of the
error-buffer.
Error-codes ≥ 10 are shown as follows:
1. n long blinks of 750 ms, which is/are an indication of the
decimal digit,
2. a pause of 1.5 s,
3. n short blinks (n = 1-9),
4. when all the error-codes are displayed, the sequence
finishes with a LED blink of 3 s,
5. the sequence starts again.
Example of error buffer: 12 9 6 0 0
After entering SDM:
1. 1 long blink of 750 ms followed by a pause of 1.5 s,
2. 2 short blinks followed by a pause of 3 s,
3. 9 short blinks followed by a pause of 3 s,
4. 6 short blinks followed by a pause of 3 s,
5. 1 long blink of 3 s to finish the sequence,
6. the sequence starts again.
Error Device Description Item Dia-
gr.
1 TEA6422D Audio switch (only Enhanced) 7798 SC13
2 MSP3451G Sound processor 7812 SC14
3 PCF8574-SCAVIO I/O expander SCAVIO 7540 SC8
4 PCF8591 AD-DA expander 7530 SC8
5 FS6377 Clock generator 7570 SC9
6 PCF8574-PSU I/O expander PSU 7370 P3
7 24C16 OTC NVM OTC 7430 SC7
8 24C16 PW NVM PW 7580 SC9
9 SAA7118 Video decoder (only Enhanced) 7225 SC5
10 AD9887 ADC/TMDS receiver 7170 SC4
11 SDA9400 De-interlacer (only Enhanced) 7280 SC5
12 EP1K30QC EPLD processor 7656 SC11
13 PDP I2C error of the PDP
20 Download comm. Errors during downloading
21 CSP comm. CSP time-out error
30 PDP Display HW error
40 Temperature alarm Detection of over-temperature
70 Vs overvoltage Overvoltage on Vs, Va, +3V3, +5V or a combination 7341 P3
71 Vs undervoltage Undervoltage on Vs 7308A/B P3
72 Va undervoltage Undervoltage on Va 7308C/D P3
73 +5V undervoltage Undervoltage on +5V 7330A/B P3
74 +3V3 undervoltage Undervoltage on +3V3 7330C/D P3
75 DC-PROT Audio amplifier protection 7362 P3
76 TEMP-PSU Over-temperature in PSU 7366A P3
77 Protection with reason unknown No valid protection can be read, but protection is active (PSU)
78 Protection after several retries PW Scaler will not start comm. with OTC after several retries.
9x OTC Internal OTC error. Replace. 7383 SC7
