Philips FW-C355 - Page 22

ELECTRICAL PARTS LIST - FRONT BOARD
4458 4822 051 30008 0R Jumper 0603
4459 4822 051 30008 0R Jumper 0603
4460 4822 051 30008 0R Jumper 0603
4461 4822 051 30008 0R Jumper 0603
4462 4822 051 30008 0R Jumper 0603
4463 4822 051 30008 0R Jumper 0603
4464 4822 051 30008 0R Jumper 0603
4465 4822 051 30008 0R Jumper 0603
4466 4822 051 30008 0R Jumper 0603
4467 4822 051 30008 0R Jumper 0603
4468 4822 051 30008 0R Jumper 0603
4469 4822 051 30008 0R Jumper 0603
4470 4822 051 30008 0R Jumper 0603
4471 4822 051 30008 0R Jumper 0603
4472 4822 051 30008 0R Jumper 0603
4473 4822 051 30008 0R Jumper 0603
4474 4822 051 30008 0R Jumper 0603
4475 4822 051 30008 0R Jumper 0603
4476 4822 051 30008 0R Jumper 0603
4477 4822 051 30008 0R Jumper 0603
4478 4822 051 30008 0R Jumper 0603
4479 4822 051 30008 0R Jumper 0603
4480 4822 051 30008 0R Jumper 0603
4481 4822 051 30008 0R Jumper 0603
4482 4822 051 30008 0R Jumper 0603
4483 4822 051 30008 0R Jumper 0603
4484 4822 051 30008 0R Jumper 0603
4485 4822 051 30008 0R Jumper 0603
4486 4822 051 30008 0R Jumper 0603
4488 4822 051 30008 0R Jumper 0603
4490 4822 051 30008 0R Jumper 0603
4491 4822 051 30008 0R Jumper 0603
4601 4822 051 30008 0R Jumper 0603
4801 4822 051 30008 0R Jumper 0603
4802 4822 051 30008 0R Jumper 0603
4803 4822 051 30008 0R Jumper 0603
4804 4822 051 30008 0R Jumper 0603
4805 4822 051 30008 0R Jumper 0603
4806 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5400 4822 157 62552 Coil 2,2µH 5%
5402 4822 242 72066 Ceram Resonator 8MHz
5403 2422 543 01069 X’tal Resonator 32,768kHz
5404 4822 157 62552 Coil 2,2µH 5%
5405 4822 157 62552 Coil 2,2µH 5%
5600 4822 157 62552 Coil 2,2µH 5%
5601 4822 157 62552 Coil 2,2µH 5%
5602 4822 157 62552 Coil 2,2µH 5%
5800 4822 157 11235 Coil 22µH 5%
DIODES
6400 4822 130 31878 1N4003G
6401 4822 130 31878 1N4003G
6402 4822 130 31878 1N4003G
6404 4822 130 30621 1N4148
6405 4822 130 30621 1N4148
6406 4822 130 30621 1N4148
6407 4822 130 30621 1N4148
6408 4822 130 30621 1N4148
6409 4822 130 30621 1N4148
6410 4822 130 30621 1N4148
6411 4822 130 30621 1N4148
6412 4822 130 30621 1N4148
6413 4822 130 30621 1N4148
6415 4822 130 30621 1N4148
6416 4822 130 30621 1N4148
6417 4822 130 30621 1N4148
6420 4822 130 30621 1N4148
6422 9322 178 15676 LTL-8166FTNN
6423 9322 178 15676 LTL-8166FTNN
6424 9322 178 15676 LTL-8166FTNN
6425 9322 178 15676 LTL-8166FTNN
6426 4822 130 30621 1N4148
6427 9322 179 76676 LTL-816EELC
6428 4822 130 30621 1N4148
6429 4822 130 30621 1N4148
6430 4822 130 30621 1N4148
6600 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
7400 3139 110 53221 TMP87CS71F “C355S53221”
7401 9352 679 67118 SAA6579T/V1/M4
7402 9322 155 22667 IR Receiver TSOP2236ZC1
7403 9965 000 04931 M24C01-WMN6
7404 4822 130 60511 BC847B
7405 4822 130 60511 BC847B
7406 4822 130 60511 BC847B
7407 4822 130 60511 BC847B
7408 4822 130 60373 BC857B
7409 4822 130 60511 BC847B
7411 4822 130 60511 BC847B
7600 4822 130 42804 BC817-25
7601 4822 130 42804 BC817-25
7602 4822 130 60373 BC857B
7800 4822 130 60511 BC847B
7801 4822 130 60511 BC847B
Note: Only the parts mentioned in this list are normal
service spare parts.
RESISTORS
6-10
