10-1
TABLE OF CONTENTS
Service Hints.....................................................................10-2
Blockdiagram ....................................................................10-5
Component Layout Main Board ........................................10-6
Circuit Diagram part1 ........................................................10-7
Component Layout Main Board ........................................10-8
Circuit Diagram part2 ........................................................10-9
Exploded View ..................................................................10-10
Partslist .............................................................................10-12
3CDC-LLC-MCD1
(3 Disc Carousel Changer)
