MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
185 D3 x 12
186 D3 x 12
211 D3 x 12
212 D3 x 12
213 D3 x 12
214 D3 x 12
215 D3 x 12
226 M3 x 6
227 M3 x 6
231 M3 x 10
232 M3 x 10
233 M3 x 10
276 M3 x 6
277 M3 x 10
283 D3 x 12
287 D3 x 12
292 D3 x 12
293 D3 x 12
294 D3 x 10
297 D3 x 12
298 D3 x 12
300 D3 x 12
101 3139 118 17211 Cabinet Front /21
101 3139 118 16860 Cabinet Front /22
101 3139 118 17300 Cabinet Front /34
103 3139 118 16961 Cover CDC Panel
106 3139 118 16871 Cover Tray CDC
108 4822 454 13408 Badge Philips
128 3139 118 17220 Window Display /21
128 3139 118 16880 Window Display /22
128 3139 118 17290 Window Display 34
133 3139 118 16390 Knob Karaoke /21
134 3139 118 16890 Button Set Power
135 3139 118 17230 Button Set Source /21
135 3139 118 16900 Button Set Source /22/34
136 3139 118 16910 Button Set Control
138 3139 118 16350 Knob Jog Rotary
139 3139 118 16360 Knob Volume Rotary
158 3139 118 16940 Cover Cassette Right
159 3139 118 16950 Cover Cassette Left
160 3139 114 74280 Lens Cassette Right
161 3139 114 74570 Lens Cassette Right Top
162 3139 114 74290 Lens Cassette Left
163 3139 114 74560 Lens Cassette Left Top
199 4822 402 10621 Push-Catch
200 4822 529 10322 Damper Assembly
201 3139 114 68640 Push Catch Left
203 4822 492 11344 Spring Compression
204 4822 402 11246 Bracket Right
205 4822 402 11245 Bracket Left
206 3139 111 01380 Spring Torsion Right
207 3139 111 01390 Spring Torsion Left
209 4822 492 70231 Spring Leaf
242 4822 462 40683 Foot Rubber SQ
268 3139 114 74620 Grommet, Mains Cord
275 4822 492 11735 Spring Trans
350 3139 118 79050 LS Box Package
9965 000 11640 Left LS Box
9965 000 11641 Right LS Box
351 4822 303 50063 FM Aerial
356 3139 118 79300 Remote Control FW-C255
384 2422 549 45067 AM Antenna Loop
385 2422 070 98145 Mains Cord 1,6M
386 4822 263 21092 Adapter Plug /21
387 3139 115 21381 Instruction For Use /21
387 3139 115 21341 Instruction For Use /22
387 3139 115 21391 Instruction For Use /34
1400 3139 110 35940 Flex Cable 30pin 18cm AD /21/34
1400 3139 110 35930 Flex Cable 32pin 18cm AD /22
1402 4822 320 12703 Flex Cable 7pin 14cm BD
1500 3139 110 35920 Flex Cable 4pin 14cm AD /21
1700 4822 320 12654 Flex Cable 7pin 22cm AD
1800 3139 110 35880 Flex Cable 15pin 18cm BD
5001 3139 118 32490 Mains Transformer /21
5001 3139 118 32481 Mains Transformer /22/34
Note: Only the parts mentioned in this list are normal service
spare parts.
