Philips FW M355 - Board Electrical Parts Lists; Mains Board Electrical Parts List

5-3
ELECTRICAL PARTS LIST - MAINS BOARD
MISCELLANEOUS
1201 4822 071 52001
!
Fuse T200mA 250V /22
1204 2422 132 07519
!
Relay 1P 12V 16A
1205 9965 000 07788
!
Fuse T2A 250V /21M
1210 2422 129 16478
!
Voltage Selector /21M
1212 4822 071 55002
!
Fuse T5A 250V
CAPACITORS
2201 5322 121 42386 100nF 5% 63V
2202 4822 121 43526 47nF 5% 250V
2203 4822 122 33449 47nF 30% 50V
2204 5322 121 42386 100nF 5% 63V
2205 4822 122 30043 10nF 63V
2206 4822 121 41856 22nF 5% 250V
2207 4822 124 40255 100uF 20% 63V
2208 4822 121 10512 220nF 20% 275V
2209 4822 122 30043 10nF 63V
2210 2020 561 90365 100nF +80/-20% 50V
2211 4822 124 41584 100uF 20% 10V
2212 4822 124 40207 100uF 20% 25V
2214 5322 122 32261 4,7nF 10% 100V
2215 4822 126 13867
!
330pF 20% 250V
RESISTORS
3202 4822 050 21003 10k 1% 0,6W
3203 4822 050 24705 4M7 1% 0,6W
3204 4822 116 52219 330R 5% 0,5W
3205 4822 116 52228 680R 5% 0,5W
3206 4822 116 52234 100k 5% 0,5W
3207 4822 116 83866 1M 5% 0,5W
3208 4822 116 83883 470R 5% 0,5W
3212 4822 050 11002 1k 1% 0,4W
3214 4822 116 52256 2k2 5% 0,5W
3215 4822 116 52234 100k 5% 0,5W
3216 4822 116 83884 47k 5% 0,5W
3218 4822 116 52283 4k7 5% 0,5W
3220 4822 116 52175 100R 5% 0,5W
3221 4822 116 52175 100R 5% 0,5W
3222 4822 050 23303 33k 1% 0,6W
3224 4822 053 21225
!
2M2 5% 0,5W
3230 4822 050 23303 33k 5% 1/6W
COILS & FILTERS
5201 4822 157 53473 Coil 1mH 10%
5202 2422 549 45157
!
Standby Transformer
5203 4822 157 53473 Coil 1mH 10%
5204 4822 157 52333 Coil 100uH 5%
5206 4822 157 11832
!
Mains Filter 400uH 3A
DIODES
6201 4822 130 31878 1N4003G
6202 4822 130 31878 1N4003G
6203 4822 130 30621 1N4148
3224 4822 053 21225 2M2 5% 0,5W
6204 4822 130 30621 1N4148
6205 4822 130 30621 1N4148
6206 4822 130 31878 1N4003G
6207 4822 130 30621 1N4148
6208 4822 130 30621 1N4148
6209 4822 130 30621 1N4148
6210 4822 130 30621 1N4148
6211 4822 130 31878 1N4003G
6212 4822 130 30621 1N4148
6213 4822 130 34173 BZX79-B5V6
6214 4822 130 31878 1N4003G
6215 4822 130 30621 1N4148
6216 4822 130 34145 BZX79-B39
6217 4822 130 30621 1N4148
6218 4822 130 30621 1N4148
6219 4822 130 34173 BZX79-B5V6
TRANSISTORS & INTEGRATED CIRCUITS
7201 4822 130 44568 BC557B
7202 4822 130 40959 BC547B
7203 4822 130 40981 BC337-25
7204 4822 130 40855 BC337-40
7205 4822 130 44568 BC557B
7206 4822 130 40959 BC547B
Note: Only the parts mentioned in this list are normal
service spare parts.
