Philips FW M355 - Front Board Application

6-26-2
Front Board application
A55470 FW-C355/21/33
A55480 FW-C355/22
A55490 FW-V355/21M
A55500 FW-C355/34
A55520 FW-M355/22
A55530 FW-M355/34
A55540 FW-M355/37
FEATURES: A55470 A55480 A55490 A55500 A55520 A55530 A55540
Karaoke / Mic Detect x - x - - - -
VCD - - x - - - -
RDS - x - x x x -
ECO Power LED - x - - x - -
ITEM NO. A55470 A55480 A55490 A55500 A55520 A55530 A55540 Functions
1427 - x x x x x - REC
1428 REC AUTO AUTO AUTO AUTO AUTO REC
1432 AUTO RDS PBC RDS RDS RDS AUTO
1433 - NEWS RETURN NEWS NEWS NEWS -
1438 - x - - x - - with LPC
1439 x - x x - x x without LPC
1801 - - x - - - - VCD & KARAOKE
1802 x - - - - - - KARAOKE
3529 - 330R 330R 330R 330R 330R - P01
3546 10k - 10k - - - 10k RDSCLK
3548 10k - 10k - - - 10k RDSDAT
3549 10k - 10k 10k - 10k 10k RESET
3565 4R7 2R2 4R7 2R2 2R2 2R2 2R2 FTD Filament
3566 - 2R2 - 2R2 2R2 2R2 2R2 FTD Filament
3567 4R7 2R2 4R7 2R2 2R2 2R2 2R2 FTD Filament
3568 - 2R2 - 2R2 2R2 2R2 2R2 FTD Filament
3569 10k - 10k 10k - 10k 10k LPC
3570 - 100k - - 100k - - RESET
3800 4k7 - 1k - - - - KARAOKE
3801 6k8 - 1k2 - - - - KARAOKE
3809 560R - 680R - - - - KARAOKE
4408 x x - x - - - CDSICL
4409 x - x x - x x +5V6
4410 - - x - x x x SH_DATA
4411 - x - x x x x HP_GND
4414 x - x x - x x DLPC
4416 x - - - - - x # AUTO
4417 - x x x x x - AUTO
4419 x - x x - x x RESET
4459 - x - - x - - +5V6_ECO
4490 x - x x - x x +5V6
4491 x - - - - - x # REC
6401 - x - - x - - +5V6_ECO
6417 - x x x x - - P01
6429 x - x - - - - KARAOKE
6430 - x - - x - - ECO Power
9401 x - x - - - - FTD Filament
9402 x - x - - - - FTD Filament
9410 - - x - x x x DSA_DATA
9411 - x - - x - - +LPS
9416 x x - x - - - CDSHDATA
9488 - x - - x - - LPC
9506 - x - - x - - +5V6_ECO
9514 - x - - x - - +5V6_ECO
x = Item in use.
