10-13
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
4868 © 4822 051 20008 CHIP JUMPER 0805
4869 © 4822 051 20008 CHIP JUMPER 0805
4870 © 4822 051 20008 CHIP JUMPER 0805
4871 © 4822 051 20008 CHIP JUMPER 0805
4872 © 4822 051 20008 CHIP JUMPER 0805
4873 © 4822 051 20008 CHIP JUMPER 0805
4874 © 4822 051 20008 CHIP JUMPER 0805
4875 © 4822 051 20008 CHIP JUMPER 0805
4876 © 4822 051 20008 CHIP JUMPER 0805
4877 © 4822 051 30008 CHIP JUMPER 0603
4879 © 4822 051 20008 CHIP JUMPER 0805
4884 © 4822 051 20008 CHIP JUMPER 0805
4885 © 4822 051 20008 CHIP JUMPER 0805
4886 © 4822 051 20008 CHIP JUMPER 0805
4887 © 4822 051 30008 CHIP JUMPER 0603
4888 © 4822 051 20008 CHIP JUMPER 0805
4889 © 4822 051 20008 CHIP JUMPER 0805
4890 © 4822 051 20008 CHIP JUMPER 0805
4891 © 4822 051 30008 CHIP JUMPER 0603
4892 © 4822 051 20008 CHIP JUMPER 0805
4893 © 4822 051 20008 CHIP JUMPER 0805
4894 © 4822 051 20008 CHIP JUMPER 0805
4895 © 4822 051 20008 CHIP JUMPER 0805
4896 © 4822 051 20008 CHIP JUMPER 0805
4897 © 4822 051 20008 CHIP JUMPER 0805
4898 © 4822 051 20008 CHIP JUMPER 0805
COILS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1810 4822 242 10849 CRYSTAL 8,46MHz
5802 2422 536 00019 TRANSFORMER, DIGITAL OUT
DIODES
–––––––––––––––––––––––––––––––––––––––––––––––––––––
6801 © 4822 130 11397 BAS316
6802 © 4822 130 11397 BAS316
6803 © 4822 130 11397 BAS316
6804 © 4822 130 11397 BAS316
6805 © 4822 130 11383 BZX284-C5V1
6807 © 4822 130 11366 BZX284-C3V9
6808 © 4822 130 11397 BAS316
6810 4822 130 31878 1N4003G
6811 © 4822 130 82334 BAS85
6812 © 4822 130 80446 BAS32L
6813 © 4822 130 11397 BAS316
TRANSISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7806 © 4822 130 60511 BC847B
7812 © 4822 130 60511 BC847B
7815 © 4822 130 60511 BC847B
7820 © 4822 130 60511 BC847B
7821 © 4822 130 60511 BC847B
7822 4822 130 42131 BF550
7823 © 4822 130 60511 BC847B
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7801 © 9352 622 36118 TZA1025T/V2 HF-Amplifier
7802 © 9352 641 81557 SAA7327M2B Signal processor
7803 © 9322 158 56682 M63000SP, MOTOR DRIVER
7813 © 5322 209 11306 HEF4094BT, SHIFT REGISTER
7814 4822 209 32852 TDA7073A/N2
ELECTRICAL PARTSLIST 3CDC-LC-VCD MODULE
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
