Philips FW M355 - Main Unit Mechanical Parts and Screw Lists

12-2
12-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
185 D3 x 12
186 D3 x 12
211 D3 x 12
212 D3 x 12
213 D3 x 12
214 D3 x 12
215 D3 x 12
226 M3 x 6
227 M3 x 6
231 M3 x 10
232 M3 x 10
233 M3 x 10
276 M3 x 6
277 M3 x 10
278 M3 x 6
283 D3 x 12
287 D3 x 12
288 D3 x 12
292 D3 x 12
293 D3 x 12
294 D3 x 10
297 D3 x 12
298 D3 x 12
300 D3 x 12
101 3139 118 17190 Cabinet Front /21M
101 3139 118 18420 Cabinet Front /22
101 3139 118 18410 Cabinet Front /34
101 3139 118 17540 Cabinet Front /37
103 3139 118 17550 Cover CDC Panel
103 3139 118 16961 Cover CDC Panel /21M
106 3139 118 17560 Cover Tray CDC
106 3139 118 17200 Cover Tray CDC /21M
108 4822 454 13408 Badge Philips
118 3139 110 00150 Badge ERCOS /21M
128 3139 118 18350 Window Display /21M
128 3139 118 18140 Window Display /22
128 3139 118 18170 Window Display /34
128 3139 118 17570 Window Display /37
133 3139 118 16390 Knob Karaoke /21M
134 3139 118 16890 Button Set Power
135 3139 118 17610 Button Set Source /21M
135 3139 118 16900 Button Set Source /22/34
135 3139 118 17230 Button Set Source /37
136 3139 118 17940 Button Set Control
136 3139 118 17620 Button Set Control /21M
138 3139 118 17690 Knob Jog Rotary
138 3139 118 16350 Knob Jog Rotary /21M
139 3139 118 17700 Knob Volume Rotary
139 3139 118 16360 Knob Volume Rotary /21M
158 3139 118 17670 Cover Cassette Right
158 3139 118 16940 Cover Cassette Right /21M
159 3139 118 17680 Cover Cassette Left
159 3139 118 16950 Cover Cassette Left /21M
160 3139 114 75940 Lens Cassette Right
160 3139 114 74280 Lens Cassette Right /21M
161 3139 114 75950 Lens Cass, Right Top
161 3139 114 74570 Lens Cass, Right Top /21M
162 3139 114 75960 Lens Cassette Left
162 3139 114 74290 Lens Cassette Left /21M
163 3139 114 75970 Lens Cass, Left Top
163 3139 114 74560 Lens Cass, Left Top /21M
199 4822 402 10621 Push-Catch
200 4822 529 10322 Damper Assembly
201 3139 114 68640 Push Catch Left
203 4822 492 11344 Spring Compression
204 4822 402 11246 Bracket Right
205 4822 402 11245 Bracket Left
206 3139 111 01380 Spring Torsion Right
207 3139 111 01390 Spring Torsion Left
209 4822 492 70231 Spring Leaf
242 4822 462 40683 Foot Rubber SQ
268 3140 113 21880 Mains Cord Relief
268 3140 113 22100 Mains Cord Relief /37
275 4822 492 11735 Spring Trans
350 3139 118 79060 LS Package FW-V355/21M
350 3139 118 79740 LS Package FW-M355/22/34
350 3139 118 79620 LS Package FW-M355/37
9965 000 11642 Left LS Box FW-V355/21M
9965 000 11602 Right LS Box FW-V355/21M
9965 000 11651 Left LS Box FW-M355/22/34
9965 000 11652 Right LS Box FW-M355/22/34
9965 000 11649 Left LS Box FW-M355/37
9965 000 11650 Right LS Box FW-M355/37
351 4822 303 50063 FM Aerial 75R
351 4822 320 11094 FM Antenna Wire /37
356 3139 228 60100 Remote Control FW-M355
356 3139 228 85100 Remote Control FW-V355
384 2422 549 45067 AM Loop Antenna
385 2422 070 98145
!
Mains Cord
385 2422 070 98203
!
Mains Cord /37
391 4822 263 21206 Cinch Cable 1,7M /21M
1400 3139 110 35940 Flex Cable 30pin 18cm AD
1400 3139 110 35930 Flex Cable 32pin 18cm AD
1402 4822 320 12703 Flex Cable 7pin 14cm BD
1500 3139 110 35690 Flex Cable 5pin 14cm AD
1700 4822 320 12654 Flex Cable 7pin 22cm AD
1800 3139 110 35880 Flex Cable 15pin 18cm BD
5001 3139 118 32520
!
Mains Transformer /21M
5001 3139 118 32510
!
Mains Transformer /22/34
5001 3139 118 32500
!
Mains Transformer /37
Note: Only the parts mentioned in this list are normal service
spare parts.
