Philips FWD39 - Location of PC Boards

1-2
/21 /21M 30
Karaoke x x x
RDS
Rotary Encoder (volume control) x x x
Jog Shuttle x x x
Voltage Selector x x
Aux Input x x x
Digital Output x x x
Headphone Socket x x x
Line Output x x x
Standby - FTD Clock Display x x x
Tuner board - ECO6 System x x x
VERSION VARIATIONS:
Type /Versions: FWD39
Features &
Board in used:
LOCATION OF PC BOARDS
POWER BOARD
TUNER BOARD
3CDC BOARD
MOTOR BOARD
CDC KEY BOARD
CONTROL BOARD
MAIN BOARD
