Align the notch on the G3 AutoDome with the
notch on the FRONT of the Pendant Arm.
NOTE: newer models use a slotted screw
instead of an allen screw.
Lift the G3 AutoDome into the Pendant Arm
and twist clockwise until the notch on the
AutoDome is aligned with the notch on the
SIDE of the pendant arm.
STEP
A13
STEP
A12
17
G3 EnviroDome 24 VAC INSTRUCTIONS
ENVX2450X and ENVX2460X Kits
User must supply a Philips LTC 5401 transformer (24 VAC,
50 VA or equivalent). Check for the following:
1. LINE VOLTAGE into transformer is between 105 to 132 VAC
for 120 VAC systems or 195 to 253 VAC for 230 VAC systems.
2.Transformer can supply between 21 and 32 VAC to the
EnviroDome under load.
3. 24 VAC wiring is adequate for powering.The following are
recommended wire run lengths at 68°F (20°C). For installa-
tions below 0°F (-20°C), reduce the run lengths by 10%.
Maximum Wiring Distance
16 AWG wire - 120 ft/37 m
18 AWG wire - 90 ft/23 m
Installation Guide
Pendant/EnviroDome
