Philips HTR5000 Service Manual

EU FM 87.5M 108M 50K
MW 531K 1602K 9K
APFM87.5M108M50K/100K
MW531K1602K9K
530K1710K10K
AREA BAND FREQUENCY (Hz) STEP(Hz)
SPECIFICATIONS
AMPLIFIER SECTION
Total Output Power (Home Theater Mode)
700W
Total Output Power (1% THD)
300W
- Front 50W
1
x 2
- Rear 50W
1
x 2
- Center 50W
1
- Subwoofer 80W
2
Frequency Response 150 HZ - 20 kHz / -3 dB
Signal-to-Noise Ratio > 60 dB (CCIR)
Input Sensitivity
- TV In 600 mV
- AUX In 600 mV
- 6 Channel In 800 mV
1
140 Hz - 20 kHz, 3ohm, 1% THD
2
40 Hz - 2 kHz, 3ohm, 1% THD
TUNER SECTION
Tuning RangeFM 87.5-108 MHz (50 kHz) (for / 01)
FM 87.5-108 MHz (50kHz /100kHz)
(for / 98)
MW531 - 1602 kHz (9kHz) (for /01)
MW531 - 1710 kHz (10kHz) (for /98)
MW531 - 1602 kHz (9kHz) (for /98)
26 dB Quieting Sensitivity FM 22 dBf
5 uV / m
Signal-to-Noise Ratio FM 55 dB
MW 40 dB
Harmonic Distortion FM Mono 3%
FM Stereo 3%
MW5%
Frequency Response FM 180 Hz-10kHz/±6 dB
Stereo Separation FM 26 dB(1 kHz)
Stereo threshold FM 23.5 dB
1-3
MAIN UNIT
Power Supply Rating 220-240V; 50Hz (for / 01)
Power Supply Rating 110-127/ 220-240V; 50/60Hz
Switchable (for / 98 )
Power Consumption 180 W
Dimensions (w x h x d) 435mm x 53mm x 359mm
Weight 4.00 kg
SPEAKERS
Front Speakers / Rear (surround) speaker
System - Front speaker 2-way. megnetically sheided
- Rear speaker 2- way
Impedance 3ohm
Speaker drivers 3'' ful-range woofer, 1''
conical dome tweeter
Frequency response 140 Hz - 20 kHz
Dimensions (w x h x d) 95mm x 175mm x 65mm
Weight 0.66 Kg / each(Front speaker)
0.77 Kg / each(Rear speaker)
CENTER SPEAKER
System 2-way. megnetically sheided
Impedance 3ohm
Speaker drivers 3'' ful-range woofer, 1''
conical dome tweeterr
Frequency response 140 Hz - 20 kHz
Dimensions (w x h x d) 220mm x 95mm x 75mm
Weight 0.8 Kg
TUNER AREA:
PASSIVE SUBWOOFER
Frequency response40 Hz - 140 Hz
Impedance 3ohm
Speaker drivers 6.5'' woofer
Power rating 100W
Dimensions (w x h x d) 130mm x 340mm x 360mm
Weight 5.11 Kg
www.nostatech.nl
www.nostatech.com

Philips HTR5000 Specifications

Sound

D/A converter	24 bit, 192 kHz
Frequency response	150 - 20 000 Hz
Signal to noise ratio	>60 dB
Distortion and Noise (1kHz)	>65 dB
Crosstalk (1kHz)	>35 dB
Dynamic Range (1kHz)	>85 dB
Output Power	5000W PMPO
Total Sound Power (RMS)	700 W
Output power (RMS)	6 x 115W

Tuner/Reception/Transmission

Tuner Bands	FM Stereo, MW
Number of Preset Channels	40
RDS	Station Name

Connectivity

Front / Side connections	Headphone Out
Other connections	TV in (audio, cinch), AUX in, Analog audio Multi-channel, Digital optical in, Digital coaxial in, Digital coaxial out, Line out, FM Antenna, MW Antenna

Power

Power supply	200-240 V, 50Hz
Power consumption	180 W
Standby power consumption	< 1 W

Loudspeakers

Satellite speaker freq range	140-20000 Hz
Satellite speaker impedance	3 ohm
Satellite speaker drivers	1" conical dome tweeter, 3" mid range woofer
Center freq range	140-20000 Hz
Center speaker impedance	3 ohm
Center speaker drivers	1" conical dome tweeter, 2x 3" mid range woofer
Subwoofer freq range	40-140 Hz
Subwoofer impedance	3 ohm
Subwoofer driver	6.5" high efficiency woofer

Dimensions

Set dimensions (W x H x D)	435 x 53 x 359 mm
Set weight	4 kg
Surround Speaker dimensions (W x H x D)	95 x 175 x 65 mm
Center speaker dimensions (W x H x D)	220 x 95 x 75 mm
Subwoofer dimensions (W x H x D)	130 x 340 x 360 mm
Packaging dimensions (W x H x D)	639 x 312 x 444 mm
Weight incl. Packaging	15.2 kg
