■ LC87F67
(IC101)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
1 0 26 2.45 51 -1 76 -3.25
2 0 27 1.02 52 -1 77 -3.25
3 0 28 1.63 53 0 78 -3.25
4 0 29 4.96 54 -17.71 79 -3.25
5 5.19 30 -1 55 -1 80 4.97
6 0 31 -1 56 -1 81 1.27
7 0 32 -1 57 -1 82 2
8 0 33 -1 58 -1 83 4.98
9 3.23 34 -1 59 -14.91 84 4.98
10 1.21 35 -1 60 1.31 85 4.79
11 4.9 36 -1 61 -3.23 86 1.83
12 0 37 -1 62 -3.23 87 0
13 4.85 38 -1 63 -3.23 88 4.79
14 0 39 -1 64 -3.23 89 0
15 2.4 40 -1 65 4.99 90 4.86
16 2.52 41 -1 66 4.93 91 4.86
17 4.98 42 -1 67 4.93 92 4.33
18 0 43 -1 68 0 93 4.99
19 0 44 -14.91 69 4.97 94 4.99
20 0 45 -1 70 4.97 95 4.86
21 3.58 46 5.4 71 0 96 4.79
22 3.59 47 -1 72 5.08 97 4.79
23 3.59 48 -1 73 0 98 0
24 3.59 49 -1 74 -3.94 99 1.79
25 0.9 50 -1 75 0 100 3.19
■ NJU7312AM(IC501)
PIN No. Volt(V) PIN No. Volt(V)
1 -12 16 0
20 17 0
30 18 0
40 19 0
50 20 0
60 21 0
70 22 0
80 23 0
90 24 0
10 0 25 0
11 0 26 0
12 0 27 0
13 28 0
14 29 0
15 30 12
■ CS4228 (IC205)
PIN No. Volt(V) PIN No. Volt(V)
1 0 16 2.5
2 0 17 2.2
3 0 18 3.5
4 1.5 19 2.2
5 1.5 20 2.2
6 1.5 21 5
722
8 3.2 23 2.3
9 2.5 24 2.3
10 1.6 25 2.3
11 0 26 2.3
12 2.9 27 2.3
13 3.2 28 2.3
14 3.2 29 2.3
■ CS49326(IC201)
PIN No. Volt(V) PIN No. Volt(V)
1 2..4 23 2.5
20 24
3 0 25 1.6
4 0 26 1.6
5271
6 2.9 28 1.6
7 0 29 1.6
8 2.4 30 1
9 2.4 31 0
10 2.4 32 2
11 2.4 33 1.3
12 2.5 34 2.5
13 0 35 0
14 2.4 36 3.2
15 2.4 37 2.5
16 2.4 38 2.5
17 2.4 39 0
18 3.2 40 0
19 1.7 41 0
20 2.4 42 1.6
21 2.4 43 1.6
22 0 44 1.6
