Philips HTS-3510 - Waveforms of Major Checkpoints

- 2-7 -
WAVEFORMS OF MAJOR CHECK POINT
• IC 208 pin
• Serial data clock waveform during normal play.
• IC 208 pin
• Serial data output wavefrom during normal
play.
1
1
(
2V/Div.
500nS/Div.
OV
(
2V/Div.
500nS/Div.
OV
(
2V/Div.
500nS/Div.
OV
384kHz
(
2V/Div.
500nS/Div.
OV
(
2V/Div.
500nS/Div.
OV
1) 2)
5 7
• IC 201 pin
• L/R clock data input wavefrom during
normal operation.
• IC 201 pin
• Bit clock data input waveform during
normal operation.
1
1
3) 4)
42
43
• IC 301 pin , , , , , , , , , , , .
• PWM data output wavefrom during normal operation.
1
5)
53
54
56 57 60
61
63
64
67
68 70
71
