EN 32
3139 785 325404.
Dismantling Instructions & Service Positions
Figure 4-31
Power Box Service Position 5
Audio Board, IO Board and Speaker Board
Figure 4-32
Power Box Service Position 6
PSU
Insulation Sheet
Speaker Board
AV Board
IO Board
Insulation Sheet
