Philips HTS8100 - Spare Parts List

EN 73
3139 785 32540
8.
Exploded View & Spare Parts List
MISCELLANEOUS
0115 313924415341 BRACKET GEARBOX HTS8100
0116 313924414991 PULLEY SMALL HTS6600
0117 313924415331 GEAR PINION HTS8100
0118 313924415321 GEAR INTERMEDIATE HTS8100
0119 313924415011 BELT HTS6600
0128 313924408661 CUSHION ASA TP DLM1D_18_12
0132 313924126101 FRAME REAR HTS8100
0161 313924125701 PLATE BOTTOM POWERBOX-07
/59 only
0230 313924126221 PLATE REAR PBOX HTS8100 LA/AP
/59 only
0337 242207600546 ANT FM WIRE 0M94 24AWG BK B
0338 242254945813 ANT AM LOOP 039S20014 B
alternative for /12
0338 242254945386 ANT AM LOOP LAN-011 B
0341 242254901403 REMOTE CONTR HTS8100/EU B
0346 313912873011
MAINS PLUG ADAPTER GR1-AX
/59 only
0347 242207600831 CBLE CINCH 1M5 CINCH 1P YE B
/37/59 only
0348 242207600675 CBLE PHONE 2M0 CINCH 2P RDWH B
/12 only
0349 242207600865 CBLE HDMI 19P 1M5 19P HDMI BKB
/37/59 only
0350 242207600912 CBLE PHONE 1M0 PHONE 3P BK B
0351 242207600891 CBLE SCART 1M5 SCART 21P BK B
/12 only
0486 313924713691 IG DOCK HTD7001/00 /12 only
0702 314010638732 FITTING-PALLET /37 only
0704 284302502961 BOARD 200P4 /12 only
0710 310310327151 STRETCHFOIL 500/15 /12 only
0716 284302502821 CORNER PROTECTOR 1100 /12 only
1010 313924851282 PCBAS PANEL FRONT HTS8100
1020 313924850892 PCBAS AV EU HTS8100 /12 only
1020 313924850812 PCBAS AV AP HTS8100 /37/59 only
1030 313924850782 PCBAS AVIO HTS8100 /37/59 only
1040 313924850792 PCBAS SCART HTS8100 /12 only
1050 313924850821 PCBAS IPOD HTS8100
1060 313924852322 PCBAS HDMI HTS8100
1070 313924851782 PCBAS SD9.2 HTS8100/12 /12 only
1070 313924850802 PCBAS SD9.2 HTS8100/37 /37 only
1070 313924851782 PCBAS SD9.2 HTS8100/12 /59 only
1080 242254901249 DVD MECHANISM KHM-313AHC Y
1090 242211500102 MOT DC 4V FC08I40TPH-1 Y
8003 313924100851 FFC FOIL 24P/180/24P AD 0.5MMP
8004 313911103761 CBLE PH 06P/180/06P PH 28ST BK
8005 310415702361 CBLE PH 05P/280/05P PH 26ST BK
8006 313911101741 CBLE MIS 11P/280/11P MIS 26OS
8007 313911103011 CBLE MIS 04P/400/04P MIS 26OS
8008 313924103031 FFC FOIL 26P/120/26P AD 0.5MMP
/12/37 only
8008 313924103721 FFC FOIL 26P/140/26P AD 0.5MMP
/59 only
8009 313924103021 FFC FOIL 50P/120/50P BD 0.5MMP
8010 313924103591 FFC FOIL 21P/240/21P AD FOLD
8011 313924103741 FFC FOIL 16P/140 AD FOLD SHLD
8012 313924103001 CBLE PH 04P/480/04P PH 26ST BK
8013 313911102671 CABLE MIS 09P/100/09P MIS 26OS
8014 313924102991 FFC FOIL 18P/120/18P AD /12 only
8015 313911034951 FFC FOIL 07P/120/07P AD /37/59 only
8016 313911027951 CBLE PH 07P/220/07P PH 26ST BK
8017 313924102981 FFC FOIL 18P/560/18P AD 1MMP
8018 313911035471 FFC FOIL 10P/220/10P BD 1MMP
8888 824115016391 Grease G-902 HTS8100 /12/37 only
P001 314107941781 DOOR PANEL PRE-ASSY/12/55
/12/59 only
P001 314107941791 DOOR PANEL PRE-ASSY/37 /37 only
P002 314107941801 FRAME DOOR PRE-ASSY/12/55
/12 only
P002 314107941811 FRAME DOOR PRE-ASSY/37
/37/59 only
P003 314107941821 BRACKET TRAVERSE PRE-ASSY
ZZ01 314107941271 COMPARTMENT DISC HTS8100 (1)
/12/37 only
SPEAKER BOX ASSEMBLY
0001 996510003246 LEFT SPEAKER MODULE
0002 996510003247 RIGHT SPEAKER MODULE
0003 996510003248 ACOUSTIC FELT
0004 996510003249 WALL MOUNT BRACKET
0005 996510003250 PCBA FRONT KEY
0006 996510003251 PCBA SWITCH KEY
0007 996510003252 GP SPK CONNECTOR
0008 996510003253 GP INTERFACE
0009 996510003254 GRILLE HOLDER-L
0010 996510003255 CABINET FRONT
0011 996510003263 DOOR COVER FOR REAR COVER
0012 996510003257 BAR MOUNT WALL
0013 996510003258 AL BAR SIDE
0014 996510003259 AL BAR TOP
0015 996510003260 AL BAR BOTTOM
0016 996510003261 RUBBER FOOT L10xW10xT1.5
0017 996510003262 RUBBERFOOT L84.76xW30.19xT5.43
SUBWOOFER TOTAL ASSY
0001 313924713441 BOX SPK ASSY SW8100
0002 313924713381 MODULE PWRBOX HTS8100 NAF
/37 only
0002 313924713631 MODULE PWRBOX HTS8100 LATAM/AP
/59/12 only
0002 313924713371 MODULE PWRBOX HTS8100 EU
/12 Only
0186 313924416041 SPACER SUPPORT-10MM /59/12 only
0238 313911426671 BUSH 450H259010 /37 only
0240 282203100024 FAN 12VDC 0.8W 3100RPM B
0345 242207098151 MAINSCORD EUR 2A5 1M5 DET 2P B
/12 only
0344 242207098235 MAINSCORD UL 6A 1M8 VH BK B
/37 only
0345 242207000062 MAINSCORD BRZ 2A5 1M8 DET 2P B
/59 only
0346 242207600917 CBLE INTERF 2CONN 5M4 4CONN B
/37 only
0346 242207600867 CBLE INTERF 2CONN 5M4 4CONN B
/59/12 only
1010 313924713432 MODULE AMP-06-01 600W(SONO)
1020 242254200032 TUN A+F ENG06806QRF USA B
1020 242254200031 TUN A+F ENG07806QRF EUR B
/12 only
1030 313924713591 PSU 07T610 US SRV2033UC MIT
/37 only
1030 313924713571 PSU 07T610 WR SRV2035WW MIT
/59 Only
1030 313924713581 PSU 07T610 EU SRV2034EK MIT
/12 only
