Philips HTS8100 - Service Hints for Dismantling of Main Unit

EN 14
3139 785 325402.
Measurements Setup, Service Aid & Lead Free Requirements
2.2.3 Service Hints for Dismantling of Main Unit
Before dismantling the main unit, unscrew the screws and
detach the door panel assembly (120+121) as shown in the
fi gure. Make sure to keep the face of the set (the door panel
121) away from scratches while dismantling or servicing the
set.
Detach Door Panel Assembly
Figure 2-15
Unscrew the screws Door Panel
