ELECTRICAL PARTS LIST - TUNER PCB ASS’Y
6-5 6-5
ANT001 9965 000 24668 RF JACK MALE TYPE 75 OHM
CN002 9965 000 15855 CONNECTOR S2B-XH-A 2 PIN
EF450-G1 9965 000 26963 TUNER PACK KWAGSUN
IF001 9965 000 24093 CERFILTER 3P 10.7MHZ
IF002 9965 000 26960 CER FILTER 3PIN 10.7M
T001 9965 000 24672 AM IFT 450KHZ 180PF Q=80MIN
T002 9965 000 24673 AM IFT 450KHZ 180PF Q=80MIN
T003 9965 000 24673 AM IFT 450KHZ 180PF Q=80MIN
T004 9965 000 24674 OSC COIL AM 120UH (796KHZ)
T005 9965 000 26964 ANT OSC AM 4-6:10T 1-3:86T
T006 9965 000 26966 BIAS COIL 78 KHZ
VC001 9965 000 26961 COND TRIM 4.2 - 20 PF N450
VD001 9965 000 26965 DIODE TUNG AM 1SV149B
VD002 9965 000 26965 DIODE TUNG AM 1SV149B
VR001 9965 000 26962 CNTL TRIMR 50KB 0.3
XL1 9965 000 23588 CRYSTAL 75KHZ +/-15
C031 9965 000 29240 CHIP CAP 0.022 UF 50V 10%
C032 9965 000 29241 CHIP CAP 0.1 UF 50V 10%
C034 9965 000 29241 CHIP CAP 0.1 UF 50V 10%
C035 9965 000 29242 CHIP CAP 15 PF 50V 5%
C036 9965 000 29243 CHIP CAP 0.22UF 50V 10%
C037 9965 000 29244 CHIP CAP 0.47 UF 50V 10%
C038 9965 000 29245 CHIP CAP 220 PF 50V 5%
C039 9965 000 29243 CHIP CAP 0.22UF 50V 10%
C040 9965 000 29246 CHIP CAP 12 PF 50V 5%
C041 9965 000 29247 CHIP CAP 0.001 UF 50V 10%
Note : Only the parts mentioned in this list are normal
service spare parts.
D001 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D002 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D004 9965 000 26958 DIODE ZENR 11.1-11.6V 0.5W
D005 9965 000 19409 DIODE CHIP BAV16W/IN4148W
TRANSISTORS & INTERGRATED CIRCUITS
DIODES
IC001 9965 000 26959 IC 44 PIN TEA5762H QFP44
Q001 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q002 4822 130 41198 2SC945P
Q003 4822 130 41198 2SC945P
Q004 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
PIN
123456789
10 11
1
21314
15 1
617
1
81920
VOLTAGE
(
FM
)
2.1 0.01
0.01 0.01 0.01
0.01
7.21 4.49
1
0.7 1.24
0.83
0.77 0.63 0.64
1.01 0.01
0
1.15 1.15
VOLTAGE(AM
)
2.1 0.01
0.01 0.01 0.01
0.01
7.45 1.12
1.36
0.58 1.24
0.18
0.77 0.63 0.64
1.01 0.01
0
1.15 1.15
PIN
21 22
23 24 25
26 27
28
29 30
31
32 33
34 35 36
37
38 39
40
VOLTAGE
(
FM
)
1.94 10.9 9.13
1.26
1.92 0.01
0.19
0.52
0.2 0.01
0.01
1.43 0.75
1.43 0.7 1.43
0.62 1.35
1.02
1.34
VOLTAGE(AM
)
1.94 10.9 9.13
1.2
1.88
0.01
0.19 0.52
0.2
0.01
0.01 1.43
1.44 1.47 1.42
1.47 1.32
1.35
1.41 1.37
PIN
41 42
43
44
VOLTAGE
(
FM
)
1.35
0.01 0.75
0.15
VOLTAGE(AM
)
1.35 0.01 0.75
0.43
IC101 (TEA5757H)
PIN
12
3
PIN
12
3
PIN 1
2
3
VOLTAGE(FM)
0.01 0.66
0.01
VOLTAGE(FM)
0.07 -0.0
3
1.3
VOLTAGE(FM)
10.12 11.8
10.77
VOLTAGE(AM)
0.01
0.66
0.01
VOLTAGE(AM)
0.08
0.01 1.24
VOLTAGE(AM)
10.17
11.81
10.82
Q101 (BF550)
Q104 (2SC945)
Q105 (2SC945)
VOL
TAGES
