MISCELLANEOUS
ELECTRICAL PARTS LIST - MAIN BOARD
8-7 8-7
CF5041 9965 000 23595 RES 2P 600KHZ ORANGE BOX
CN201 9965 000 27002 CONNECTOR 9 PIN
CN202 9965 000 27000 CONNECTOR 7 PIN
CN5001 9965 000 26994 CONNECTOR 4 PIN
CN801 9965 000 25152 CHIP CONNECTOR 24PIN
CN802 9965 000 26996 CONNECTOR 6 PIN
CN803 9965 000 26995 CONNECTOR 5 PIN
CN901 9965 000 25151 CONNECTOR 3 PIN CL3962WVO
CN902 9965 000 25149 CONNECTOR B8B-XH-A 8 PIN
CN903 9965 000 26993 CONNECTOR 3 PIN
FB5003 9965 000 26925 CHIP INDUC 10 UH 0.1 SMD
JK401 9965 000 24074 RCA JACK 6P WHTX3/RED
JK501 9965 000 25157 SPK JACK 12PIN
JK802 9965 000 25153 RCA+DIN JK 1RCA+4P
JK803 9965 000 29232 SCART SOCK 21PIN
JK805 9965 000 25156 RCA JACK 1 PIN BLAK
L187 9965 000 23594 CHIP INDUC 1UH 10%
L202 9965 000 26926 CHIP INDUC 1 UH 0.1
L203 9965 000 26926 CHIP INDUC 1 UH 0.1
L204 9965 000 26926 CHIP INDUC 1 UH 0.1
L205 9965 000 26926 CHIP INDUC 1 UH 0.1
L206 9965 000 23594 CHIP INDUC 1UH 10%
L207 9965 000 26944 CHIP BEAD 60 OHM 100MHZ
L208 9965 000 23594 CHIP INDUC 1UH 10%
L351 9965 000 26926 CHIP INDUC 1 UH 0.1
L352 9965 000 26926 CHIP INDUC 1 UH 0.1
L5001 9965 000 26938 INDUCTOR 100 UH 0.1
L5002 9965 000 26938 INDUCTOR 100 UH 0.1
L501 9965 000 23892 INDUCTOR 47UH 20% 4.3A
L502 9965 000 23892 INDUCTOR 47UH 20% 4.3A
L955 9965 000 26938 INDUCTOR 100 UH 0.1
L957 9965 000 26938 INDUCTOR 100 UH 0.1
L958 9965 000 26649 INDUCTOR 6UH 14.5TS 2UEW
L203 9965 000 26926 CHIP INDUC 1 UH 0.1
L204 9965 000 26926 CHIP INDUC 1 UH 0.1
L205 9965 000 26926 CHIP INDUC 1 UH 0.1
L206 9965 000 23594 CHIP INDUC 1UH 10%
L207 9965 000 26944 CHIP BEAD 60 OHM 100MHZ
L208 9965 000 23594 CHIP INDUC 1UH 10%
L351 9965 000 26926 CHIP INDUC 1 UH 0.1
L352 9965 000 26926 CHIP INDUC 1 UH 0.1
L5001 9965 000 26938 INDUCTOR 100 UH 0.1
L5002 9965 000 26938 INDUCTOR 100 UH 0.1
L501 9965 000 23892 INDUCTOR 47UH 20% 4.3A
L502 9965 000 23892 INDUCTOR 47UH 20% 4.3A
L503 9965 000 23892 INDUCTOR 47UH 20% 4.3A
L504 9965 000 23892 INDUCTOR 47UH 20% 4.3A
L5041 9965 000 23594 CHIP INDUC 1UH 10%
L505 9965 000 23892 INDUCTOR 47UH 20% 4.3A
L506 9965 000 23893 INDUCTOR 33UH 20% 6A
L801 9965 000 26926 CHIP INDUC 1 UH 0.1
L802 9965 000 26926 CHIP INDUC 1 UH 0.1
L803 9965 000 23594 CHIP INDUC 1UH 10%
L804 9965 000 23895 CHIP INDUC 2.4UH 5%
L805 9965 000 23895 CHIP INDUC 2.4UH 5%
L806 9965 000 23895 CHIP INDUC 2.4UH 5%
L807 9965 000 23895 CHIP INDUC 2.4UH 5%
L808 9965 000 23895 CHIP INDUC 2.4UH 5%
L812 9965 000 23594 CHIP INDUC 1UH 10%
L813 9965 000 23594 CHIP INDUC 1UH 10%
L814 9965 000 23594 CHIP INDUC 1UH 10%
L815 9965 000 26926 CHIP INDUC 1 UH 0.1
L816 9965 000 26926 CHIP INDUC 1 UH 0.1
L817 9965 000 26926 CHIP INDUC 1 UH 0.1
L818 9965 000 26926 CHIP INDUC 1 UH 0.1
L819 9965 000 23594 CHIP INDUC 1UH 10%
Note : Only the parts mentioned in this list are normal
service spare parts.
L820 9965 000 23594 CHIP INDUC 1UH 10%
L821 9965 000 23594 CHIP INDUC 1UH 10%
L822 9965 000 23594 CHIP INDUC 1UH 10%
L823 9965 000 26926 CHIP INDUC 1 UH 0.1
RESISTORS
RB151 9965 000 27001 CONNECTOR 8 PIN
RN201 9965 000 23613 CHIP ARRAY 4X4.7KOHM
RN202 9940 000 00865 RES ARRAY 4X33R 1/10W 5%
RN203 9940 000 00865 RES ARRAY 4X33R 1/10W 5%
RN204 9965 000 23613 CHIP ARRAY 4X4.7KOHM
RN205 9965 000 23614 CHIP ARRAY 10 OHMX4
RN206 9965 000 23614 CHIP ARRAY 10 OHMX4
RN207 9965 000 23614 CHIP ARRAY 10 OHMX4
RN208 9940 000 00865 RES ARRAY 4X33R
RN210 9965 000 23613 CHIP ARRAY 4X4.7KOHM
RN211 9940 000 00865 RES ARRAY 4X33R 1/10W 5%
XL201 9965 000 23929 CRYSTAL27MHZ HC-49/US
CAPACTIORS
C511 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C512 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C523 9965 000 23896 CHIP CAP 560PF 100V 10%
C524 9965 000 23896 CHIP CAP 560PF 100V 10%
C525 9965 000 23896 CHIP CAP 560PF 100V 10%
C526 9965 000 23896 CHIP CAP 560PF 100V 10%
C527 9965 000 23605 COND MYLAR 0.01UF 100V 5%
C528 9965 000 23605 COND MYLAR 0.01UF 100V 5%
C541 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C542 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C563 9965 000 23896 CHIP CAP 560PF 100V 10%
C564 9965 000 23896 CHIP CAP 560PF 100V 10%
C565 9965 000 23896 CHIP CAP 560PF 100V 10%
C566 9965 000 23896 CHIP CAP 560PF 100V 10%
C567 9965 000 23605 COND MYLAR 0.01UF 100V 5%
C568 9965 000 23605 COND MYLAR 0.01UF 100V 5%
C580 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C581 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C591 9965 000 23896 CHIP CAP 560PF 100V 10%
C592 9965 000 23896 CHIP CAP 560PF 100V 10%
C593 9965 000 23605 COND MYLAR 0.01UF 100V 5%
C596 9965 000 23896 CHIP CAP 560PF 100V 10%
C597 9965 000 23896 CHIP CAP 560PF 100V 10%
C598 9965 000 23605 COND MYLAR 0.01UF 100V 5%
C951 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C952 9965 000 26917 CHIP CAP 0.1UF/100V X7R /- 0.1
C955 5322 124 22614 1000UF20% 50V
C956 5322 124 22614 1000UF20% 50V
C961 9965 000 23606 COND ELECT 1000UF 16V 20%
DIODES
D301 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D302 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D303 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D304 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D305 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D306 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D307 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D308 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D309 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D310 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D311 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D312 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D313 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D314 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D315 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D316 9965 000 19409 DIODE CHIP BAV16W/IN4148W
D317 9965 000 19409 DIODE CHIP BAV16W/IN4148W
