1 Connect the supplied MW loop antenna to the
MW jack. Place the MW loop antenna on a
shelf or attach it to a stand or wall.
2 Connect the supplied FM antenna to the FM
(75Ω) jack. Extend the FM antenna and fix its
ends to the wall.
For better FM stereo reception, connect an
external FM antenna (not supplied).
Helpful Hints:
– Adjust the position of the antennas for optimal
reception.
– Position the antennas as far as possible from
your TV, VCR or other radiation source to prevent
unwanted interference.
After everything is connected properly,
plug the AC power cord into the power
outlet.
Never make or change any connections with
the power switched on.
Helpful Hint:
– Refer to the type plate on the rear or bottom of
the system for identification and supply ratings.
