Philips MX3900D - Page 110

11-11
RESISTORS
3311 4822 117 13578 RES NETWORK 4 X 10k 5% 1206
3312 4822 117 13578 RES NETWORK 4 X 10k 5% 1206
3313 3198 031 11010 RST NETWORK 4 X 100R 5% 1206
3314 3198 031 11010 RST NETWORK 4 X 100R 5% 1206
3315 3198 031 11010 RST NETWORK 4 X 100R 5% 1206
3316 3198 031 11010 RST NETWORK 4 X 100R 5% 1206
4016 4822 051 30008 0R JUMPER 0603
4021 4822 051 30008 0R JUMPER 0603
4023 4822 051 30008 0R JUMPER 0603
4024 4822 051 30008 0R JUMPER 0603
4036 4822 051 30008 0R JUMPER 0603
4041 4822 051 30008 0R JUMPER 0603
4044 4822 051 30008 0R JUMPER 0603
4052 4822 051 30008 0R JUMPER 0603
4056 4822 051 30008 0R JUMPER 0603
4062 4822 051 30008 0R JUMPER 0603
4100 4822 051 30008 0R JUMPER 0603
COILS & FILTERS
5002 4822 157 71206 IND FXD 100MHZ 600R
5003 4822 157 71206 IND FXD 100MHZ 600R
5004 4822 157 71206 IND FXD 100MHZ 600R
5006 4822 157 71206 IND FXD 100MHZ 600R
5007 4822 157 71206 IND FXD 100MHZ 600R
5008 4822 157 71206 IND FXD 100MHZ 600R
5010 4822 157 71206 IND FXD 100MHZ 600R
5011 4822 157 71206 IND FXD 100MHZ 600R
5300 4822 242 10757 X’TAL RESONATOR 33,868MHZ 20P
DIODES
6002 4822 130 11397 BAS316
6003 4822 130 11397 BAS316
6004 4822 130 11397 BAS316
6005 4822 130 11397 BAS316
6006 4822 130 11397 BAS316
6007 4822 130 11397 BAS316
6008 4822 130 11397 BAS316
TRANSISTORS & INTEGRATED CIRCUITS
7101 9322 186 11671 M5705
7102 9322 185 60671 SP3721AAA0PM
7104 4822 209 32073 MC34072D
7105 9965 000 19029 M29F002BT-70K1 with SW program
7107 9322 159 55668 K4S161622D-TC70
7109 9322 187 63668 BA5954FP
7110 4822 209 32073 MC34072D
7201 4822 130 11565 2SB1132
7202 4822 130 11565 2SB1132
7203 9340 547 13215 BSH103
7204 4822 130 42804 BC817-25
7205 4822 130 42804 BC817-25
7206 9340 547 13215 BSH103
ELECTRICAL PARTS LIST - MONO-FE BOARD
7207 4822 130 42804 BC817-25
7208 9322 163 24668 L78M08CDT
Note: Only the parts mentioned in this list are normal service
spare parts.
