MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT
SCREW LISTS - MAIN UNIT
185 M3 x 6
186 D3 x 10
187 M3 x 6
188 M3 x 6
228 M3 x 6
229 M3 x 6
230 D3 x 10
233 M3 x 6
235 D3 x 10
276 D3 x 10
277 D3 x 10
278 D3 x 10
279 D2 x 8
280 D2 x 8
281 D2 x 8
282 M3 x 6
283 M3 x 6
284 M3 x 6
285 D3 x 10
286 M3 x 6
287 M3 x 6
288 D3 x 10
290 D3 x 10
291 D3 x 10
292 D3 x 10
293 D3 x 10
295 M3 x 6
296 M5 x 6 Hex W/Head
297 M3 x 6
101 3139 118 18791 Cabinet Front Silver
MX3900D
101 3139 257 51651 Cabinet Front MX3910D
101 3139 257 50461 Cabinet Front Dark Grey MX3950D
101 3139 257 51641 Cabinet Front MX3960D
102 3139 118 18801 Cover Cab Side Left Silver
102 3139 257 50471 Cover Cab Side L Dark Grey
103 3139 118 18811 Cover Cab Side Right Silver
103 3139 257 50481 Cover Cab Side R Dark Grey
105 3139 118 18821 Cover Tray Disc 1 Silver
105 3139 257 50491 Cover Tray Disc 1 Dark Grey
106 3139 118 19101 Cover Tray Disc 2 Silver
106 3139 257 50501 Cover Tray Disc 2 Dark Grey
107 3139 118 19111 Cover Tray Disc 3 Silver
107 3139 257 50511 Cover Tray Disc 3 Dark Grey
108 3139 118 19121 Cover Tray Disc 4 Silver
108 3139 257 50521 Cover Tray Disc 4 Dark Grey
109 3139 118 19131 Cover Tray Disc 5 Silver
109 3139 257 50531 Cover Tray Disc 5 Dark Grey
120 3139 118 19441 Button Set CD Open/Close Chrome
122 3139 113 27511 Cutsheet Shield CD Open/Close
123 3139 118 18831 Panel Left Silver
MX3900D
123 3139 257 51671 Panel Left MX3910D
123 3139 257 50541 Panel Left Dark Grey MX3950D
123 3139 257 51661 Panel Left MX3960D
124 3139 118 18841 Window Display
125 3139 118 18851 Panel Display Silver
125 3139 257 50551 Panel Display Dark Grey
126 3139 118 18861 Panel Control Silver
126 3139 257 50561 Panel Control Dark Grey
127 3139 118 18871 Button Set Power Eco Silver
127 3139 257 50571 Button Set Power Eco Dark Grey
128 3139 114 77041 Lightguide Power Eco Stdby
133 3139 118 18941 Ring Ornamental
134 3139 118 18931 Cap Knob Rotary Chrome
135 3139 118 18921 Knob Source/Volume Rotary
136 3139 118 19461 Button Set Bass Chrome
137 3139 118 19471 Button Set Treble Chrome
140 3139 118 19451 Button Set Source Control Chrome
256 3139 113 27220 Foot Rubber
259 3139 111 01470 Spring Grounding
296 3139 110 40691 Screw M5x6 Hex W/Head Chrome
296 3139 110 40701 Screw M5x6 Hex W/Head Black
345 3139 119 01381 Satellite LS Package CS3900D/17S
345 3139 119 01401 Satellite LS Package CS3950D/17S
346 3139 119 01391 Subwoofer Box SW3900/17S
346 3139 119 01411 Subwoofer Box SW3950D/17s
351 4822 303 50063 FM Antenna
352 4822 303 50082 AM Loop Antenna
353 3139 228 61701 Remote Control RC19241001/01
356 2422 070 98246
!
Mains Cord UL 7A 1,5M
358 4822 263 21206 Cable Video 1,7M Yellow
361 2422 076 00374 Cable Cinch 1,5M Gn/Bu/Rd
362 3103 308 92610 Cable Audio 1,5M 2x2 RCA
370 3139 115 21991 Instruction for Use
MX3900D/MX3950D
1110 3103 308 52950 Fan Assembly KD1206PTS3
5001 3139 118 32661
!
Mains Transfo. PWR207 6x75W/37
8000 3139 110 35031 FFC Cable Pin 14cm AD
8001 3139 111 02001 FFC Cable 13Pin 40cm BD
8002 3139 111 02041 FFC Cable 17Pin 40cm AD
8003 3139 111 02271 FFC Cable 13Pin 10cm AD
8005 3139 111 02051 FFC Cable 7Pin 34cm AD
8006 3139 110 34860 FFC Cable 4Pin 34cm AD
8008 3139 111 02021 FFC Cable 4Pin 22cm AD
8010 3139 111 02601 FFC Cable 16Pin 18cm AD
8011 3139 111 02591 FFC Cable 10Pin 28cm AD
8012 3139 111 02581 FFC Cable 13Pin 18cm AD
8013 3139 111 02571 FFC Cable 10Pin 18cm BD
8014 3139 111 02571 FFC Cable 10Pin 18cm BD
8016 3139 110 36140 FFC Cable 4Pin 18cm AD
8018 3139 111 02231 FFC Cable 5Pin 12cm AD
Note: Only the parts mentioned in this list are normal service
spare parts.
Breakdown of Satellite LS Package CS3900D/17S (Applicable
for MX3900D & MX3910D only)
9965 000 17040 Front Left Speaker Box
9965 000 17041 Front Right Speaker Box
9965 000 17042 Surround Left Speaker Box
9965 000 17043 Surround Right Speaker Box
9965 000 17044 Center Speaker Box
9965 000 17045 Front Grille Assy (Center Speaker)
9965 000 17046 Philips Logo (Center Speaker)
9965 000 17047 Keyhole Bracket Pack set Silver
Breakdown of Satellite LS Package CS3950D/17S (Applicable
for MX3950D & MX3960D only)
9965 000 17050 Front Left Speaker Box
9965 000 17051 Front Right Speaker Box
9965 000 17052 Surround Left Speaker Box
9965 000 17053 Surround Right Speaker Box
9965 000 17054 Center Speaker Box
9965 000 17055 Front Grille Assy (Center Speaker)
9965 000 17046 Philips Logo (Center Speaker)
9965 000 17056 Keyhole Bracket Pack Set Black
Breakdown of SW3900/17S & SW3950/17S (Applicable for all)
9965 000 17048 Front Grille Assy SW3900/17S
9965 000 17049 Front Grille Assy SW3950/17S
9965 000 17046 Philips Logo
Note: Only the parts mentioned in this list are normal service
spare parts.
