Philips MX3900D - Page 35

ELECTRICAL PARTS LIST - FRONT BOARDS
6-9
RESISTORS
4301 4822 051 30008 0R Jumper 0603
4302 4822 051 30008 0R Jumper 0603
4303 4822 051 30008 0R Jumper 0603
4304 4822 051 30008 0R Jumper 0603
4305 4822 051 30008 0R Jumper 0603
4306 4822 051 30008 0R Jumper 0603
4307 4822 051 30008 0R Jumper 0603
4308 4822 051 30008 0R Jumper 0603
4309 4822 051 30008 0R Jumper 0603
4310 4822 051 30008 0R Jumper 0603
4311 4822 051 30008 0R Jumper 0603
4312 4822 051 30008 0R Jumper 0603
4313 4822 051 30008 0R Jumper 0603
4314 4822 051 30008 0R Jumper 0603
4315 4822 051 30008 0R Jumper 0603
4316 4822 051 30008 0R Jumper 0603
4317 4822 051 30008 0R Jumper 0603
4318 4822 051 30008 0R Jumper 0603
4319 4822 051 30008 0R Jumper 0603
4320 4822 051 30008 0R Jumper 0603
4321 4822 051 30008 0R Jumper 0603
4323 4822 051 30008 0R Jumper 0603
4324 4822 051 30008 0R Jumper 0603
4325 4822 051 30008 0R Jumper 0603
4326 4822 051 30008 0R Jumper 0603
4327 4822 051 30008 0R Jumper 0603
4328 4822 051 30008 0R Jumper 0603
4329 4822 051 30008 0R Jumper 0603
4330 4822 051 30008 0R Jumper 0603
4332 4822 051 30008 0R Jumper 0603
4334 4822 051 30008 0R Jumper 0603
4337 4822 051 30008 0R Jumper 0603
4338 4822 051 30008 0R Jumper 0603
4339 4822 051 30008 0R Jumper 0603
4342 4822 051 30008 0R Jumper 0603
4343 4822 051 30008 0R Jumper 0603
4400 4822 051 30008 0R Jumper 0603
4500 4822 051 30008 0R Jumper 0603
4501 4822 051 30008 0R Jumper 0603
4600 4822 051 30008 0R Jumper 0603
4601 4822 051 30008 0R Jumper 0603
4602 4822 051 30008 0R Jumper 0603
4605 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5100 3198 018 52280 Coil 2,2uH 10% 0603
5102 5322 242 73686 Ceram Resonator 12MHz
5103 4822 242 70938 X’tal Resonator 32,768kHZ
5104 3198 018 52280 Coil 2,2uH 10% 0603
5600 2422 549 44608 Ind Fxd 100MHz 1k
5604 2422 549 44608 Ind Fxd 100MHz 1k
5605 2422 549 44608 Ind Fxd 100MHz 1k
5606 2422 549 44608 Ind Fxd 100MHz 1k
DIODES
6100 4822 130 30621 1N4148
6101 4822 130 30621 1N4148
6103 4822 130 30621 1N4148
6106 4822 130 31878 1N4003G
6105 4822 130 80622 BAT54
6107 4822 130 83206 BZX79-B5V6
6108 4822 130 11397 BAS316
6113 4822 130 31878 1N4003G
6118 4822 130 80622 BAT54
6119 4822 130 31878 1N4003G
6308 4822 130 11416 BZX384-C6V8
6309 4822 130 11416 BZX384-C6V8
6310 4822 130 11416 BZX384-C6V8
6311 4822 130 11416 BZX384-C6V8
6500 9322 179 76676 LTL-816EELC
6501 9322 183 96676 LTL-816GE
TRANSISTORS & INTEGRATED CIRCUITS
7100 3139 110 53491 TMP88CU74F with "3900S53491"
7103 9322 145 26668 M24C02-WMN6
7104 5322 130 60159 BC847B
7105 5322 130 60159 BC847B
7106 5322 130 60159 BC847B
7107 5322 130 60159 BC847B
7108 5322 130 60159 BC847B
7109 5322 130 60159 BC847B
7500 5322 130 60159 BC847B
7501 9322 185 97667 IR RECEIVER TSOP4836ZC1
7504 5322 130 60159 BC847B
Note: Only the parts mentioned in this list are normal service
spare parts.
