ELECTRICAL PARTS LIST - AV BOARDELECTRICAL PARTS LIST - AV BOARD
MISCELLANEOUS
1181 2422 026 05399 Socket Cinch Dig-out/Aux-in
1182 4822 267 31823 Socket Cinch TV-in/Line-out
1183 2422 033 00468 Socket CVBS/S-Video Out
1184 2422 026 05342 Socket YUV Out
1187 2422 127 00476 Switch Pro-SCAN
1230 4822 267 10733 FFC Socket 4P Vert.
1231 4822 267 10729 FFC Socket 10P Vert.
1232 4822 267 10733 FFC Socket 4P Vert.
1234 4822 267 10729 FFC Socket 10P Vert.
1236 4822 267 10954 FFC Socket 5P Vert.
1237 4822 265 11515 FFC Socket 8P Vert.
1238 4822 267 10738 FFC Socket 13P Vert.
1239 4822 267 10871 FFC Socket 17P Vert.
1242 2422 025 16591 FFC Socket 13P Vert.
1401 2422 025 16525 FFC Socket 16P Vert.
1405 2422 025 16587 FFC Socket 10P Vert.
CAPACITORS
2100 3198 016 31020 1nF 10% 25V
2101 3198 016 31020 1nF 10% 25V
2102 2238 586 59812 100nF 10% 50V
2103 2020 552 94427 100pF 5% 50V
2104 2020 552 94427 100pF 5% 50V
2105 3198 017 44740 470nF 10V
2106 3198 017 44740 470nF 10V
2107 2020 552 96327 330nF 10% 16V
2108 4822 126 13879 220nF +80/-20% 16V
2109 2020 552 94427 100pF 5% 50V
2110 5322 126 11579 3,3nF 10% 63V
2111 3198 016 31020 1nF 10% 25V
2112 5322 126 11583 10nF 10% 50V
2113 3198 017 44740 470nF 10V
2114 3198 017 44740 470nF 10V
2115 2020 552 96327 330nF 10% 16V
2116 4822 126 13879 220nF +80/-20% 16V
2117 4822 126 14238 2,2nF 50V
2118 5322 126 11579 3,3nF 10% 63V
2119 3198 016 31020 1nF 10% 25V
2120 5322 126 11583 10nF 10% 50V
2121 3198 017 44740 470nF 10V
2122 4822 126 14494 22nF 10% 25V
2123 4822 124 81151 22uF 20% 50V
2124 4822 124 40196 220uF 20% 16V
2125 4822 126 14238 2,2nF 50V
2126 4822 124 40433 47uF 20% 25V
2127 2020 552 94427 100pF 5% 50V
2128 2020 552 94427 100pF 5% 50V
2129 2238 586 59812 100nF 10% 50V
2130 2238 586 59812 100nF 10% 50V
2135 Refer to resistor 3310
2136 2238 586 59812 100nF 10% 50V
2139 2238 586 59812 100nF 10% 50V
2143 2238 586 59812 100nF 10% 50V
2144 4822 126 13956 68pF 5% 63V
2145 4822 126 13956 68pF 5% 63V
2150 4822 126 14043 1uF +80/-20% 16V
2151 4822 126 14043 1uF +80/-20% 16V
2152 3198 016 38210 820pF 10% 25V
2153 3198 016 38210 820pF 10% 25V
2154 4822 126 14043 1uF +80/-20% 16V
2155 4822 126 14043 1uF +80/-20% 16V
2156 2020 552 94427 100pF 5% 50V
2157 2020 552 94427 100pF 5% 50V
2160 4822 126 13956 68pF 5% 63V
2161 4822 126 13956 68pF 5% 63V
2162 4822 126 14491 2,2uF +80/-20% 10V
2163 3198 016 31020 1nF 10% 25V
2164 3198 016 31020 1nF 10% 25V
2165 3198 016 31020 1nF 10% 25V
2166 4822 124 40769 4,7uF 20% 100V
2167 4822 126 14491 2,2uF +80/-20% 10V
2168 3198 016 31020 1nF 10% 25V
2170 4822 126 14238 2,2nF 50V
2172 3198 017 34730 47nF 16V
2173 3198 017 34730 47nF 16V
2187 2238 586 59812 100nF 10% 50V
2188 2238 586 59812 100nF 10% 50V
2190 2020 552 94427 100pF 5% 50V
2191 2020 552 94427 100pF 5% 50V
2192 2020 552 94427 100pF 5% 50V
2193 2020 552 94427 100pF 5% 50V
2194 2020 552 94427 100pF 5% 50V
2195 2020 552 94427 100pF 5% 50V
2196 2020 552 94427 100pF 5% 50V
2197 2020 552 94427 100pF 5% 50V
2198 2020 552 94427 100pF 5% 50V
2201 4822 124 40184 1000uF 20% 10V
2202 4822 124 40248 10uF 20% 63V
2207 4822 124 41751 47uF 20% 50V
2208 4822 124 41751 47uF 20% 50V
2209 4822 126 14508 180pF 5% 50V
2210 4822 126 14508 180pF 5% 50V
2211 4822 126 13881 470pF 5% 50V
2212 4822 126 13881 470pF 5% 50V
2213 2020 552 94427 100pF 5% 50V
2214 3198 016 31020 1nF 10% 25V
2215 4822 124 81151 22uF 20% 50V
2216 3198 016 31020 1nF 10% 25V
2217 4822 124 81151 22uF 20% 50V
2218 2020 552 94427 100pF 5% 50V
2219 4822 124 40433 47uF 20% 25V
2220 4822 126 14494 22nF 10% 25V
2224 4822 124 81151 22uF 20% 50V
2225 4822 124 81151 22uF 20% 50V
2226 4822 124 40255 100uF 20% 63V
2227 4822 124 81151 22uF 20% 50V
2228 4822 124 40255 100uF 20% 63V
2229 4822 124 40255 100uF 20% 63V
2230 4822 124 81151 22uF 20% 50V
2231 4822 124 80791 470uF 20% 16V
2232 4822 124 40196 220uF 20% 16V
2233 4822 124 41584 100uF 20% 10V
2240 2020 012 93583 100uF 20% 25V
2241 3198 026 51020 1000uF 20% 50V
2242 4822 124 40433 47uF 20% 25V
2254 3198 017 44740 470nF 10V
2280 3198 017 44740 470nF 10V
2281 3198 017 44740 470nF 10V
2282 3198 017 44740 470nF 10V
2283 3198 017 44740 470nF 10V
2302 3198 017 44740 470nF 10V
2303 2238 586 59812 100nF 10% 50V
2304 3198 017 44740 470nF 10V
2305 2020 552 94427 100pF 5% 50V
2308 2020 552 94427 100pF 5% 50V
2309 4822 126 13193 4,7nF 10% 63V
2310 4822 126 13193 4,7nF 10% 63V
2311 4822 124 40433 47uF 20% 25V
2312 4822 126 14494 22nF 10% 25V
2313 4822 124 40433 47uF 20% 25V
2314 3198 016 31020 1nF 10% 25V
2318 3198 017 41050 1uF +80/-20% 10V
2319 3198 017 44740 470nF 10V
2320 3198 017 44740 470nF 10V
2321 3198 017 44740 470nF 10V
2322 3198 017 44740 470nF 10V
2324 4822 124 12032 4,7uF 20% 50V
2325 2020 552 94427 100pF 5% 50V
2326 3198 017 44740 470nF 10V
2327 2020 552 94427 100pF 5% 50V
2328 2020 552 94427 100pF 5% 50V
2329 2020 552 96684 470nF 10% 16V
2330 4822 126 14472 1uF 10% 10V
2331 4822 126 13193 4,7nF 10% 63V
2332 2020 552 96684 470nF 10% 25V
2333 2020 552 96326 220nF 10% 16V
2334 2222 780 15656 330nF 10% 16V
2335 2020 552 94427 100pF 5% 50V
2336 4822 124 40433 47uF 20% 25V
2337 4822 126 14494 22nF 10% 25V
2338 4822 124 40433 47uF 20% 25V
2339 3198 016 31020 1nF 10% 25V
2340 2020 552 94427 100pF 5% 50V
2341 4822 126 14043 1uF +80/-20% 16V
2342 4822 126 14043 1uF +80/-20% 16V
2343 4822 126 14043 1uF +80/-20% 16V
2344 4822 126 14043 1uF +80/-20% 16V
2349 2238 586 59812 100nF 10% 50V
2352 3198 017 41050 1uF +80/-20% 10V
2353 2238 586 59812 100nF 10% 50V
2380 2020 552 96684 470nF 10% 25V
2390 2020 552 94427 100pF 5% 50V
2391 2020 552 94427 100pF 5% 50V
2392 2020 552 94427 100pF 5% 50V
2393 2020 552 94427 100pF 5% 50V
2394 2020 552 94427 100pF 5% 50V
2395 2020 552 94427 100pF 5% 50V
2396 2020 552 94427 100pF 5% 50V
2397 2020 552 94427 100pF 5% 50V
2402 2238 586 59812 100nF 10% 50V
2407 4822 126 13883 220pF 5% 50V
2409 4822 126 13883 220pF 5% 50V
2410 4822 126 13883 220pF 5% 50V
2411 2020 552 94427 100pF 5% 50V
2412 2020 552 94427 100pF 5% 50V
2413 2020 552 94427 100pF 5% 50V
2417 2020 552 94427 100pF 5% 50V
2418 2020 552 94427 100pF 5% 50V
2420 4822 124 40196 220uF 20% 16V
2421 4822 124 40196 220uF 20% 16V
2422 2238 586 59812 100nF 10% 50V
2423 4822 126 14249 560pF 25V
2424 2238 586 59812 100nF 10% 50V
2425 3198 016 31020 1nF 50V
2426 5322 126 11583 10nF 10% 50V
2427 4822 126 14508 180pF 5% 50V
2428 4822 126 11785 47pF 5% 50V
2429 4822 126 14241 330pF 50V
2445 2020 552 96305 4,7uF +80/-20% 10V
2446 2020 552 96305 4,7uF +80/-20% 10V
2450 2238 586 59812 100nF 10% 50V
2451 2238 586 59812 100nF 10% 50V
RESISTORS
3100 4822 051 30221 220R 5% 0,062W
3101 4822 051 30221 220R 5% 0,062W
3102 4822 051 30102 1k 5% 0,062W
3103 4822 051 30102 1k 5% 0,062W
3104 4822 051 30562 5k6 5% 0,063W
3105 4822 117 12902 8k2 1% 0,063W
3106 4822 051 30562 5k6 5% 0,063W
3107 4822 051 30183 18k 5% 0,062W
3108 4822 051 30103 10k 5% 0,062W
3109 4822 117 12925 47k 1% 0,063W
3110 4822 051 30682 6k8 5% 0,062W
3111 4822 051 30562 5k6 5% 0,063W
3112 4822 117 12902 8k2 1% 0,063W
3113 4822 051 30183 18k 5% 0,062W
