ELECTRICAL PARTS LIST - AV BOARD
9-10 9-10
RESISTORS
4428 4822 051 30008 0R Jumper 0603
4500 4822 051 30008 0R Jumper 0603
4501 4822 051 30008 0R Jumper 0603
4502 4822 051 30008 0R Jumper 0603
4503 4822 051 30008 0R Jumper 0603
4504 4822 051 30008 0R Jumper 0603
4505 4822 051 30008 0R Jumper 0603
4506 4822 051 30008 0R Jumper 0603
4507 4822 051 30008 0R Jumper 0603
4508 4822 051 30008 0R Jumper 0603
4510 4822 051 30008 0R Jumper 0603
4511 4822 051 30008 0R Jumper 0603
4512 4822 051 30008 0R Jumper 0603
4513 4822 051 30008 0R Jumper 0603
4514 4822 051 30008 0R Jumper 0603
4515 4822 051 30008 0R Jumper 0603
4516 4822 051 30008 0R Jumper 0603
4517 4822 051 30008 0R Jumper 0603
4518 4822 051 30008 0R Jumper 0603
4519 4822 051 30008 0R Jumper 0603
4520 4822 051 30008 0R Jumper 0603
4521 4822 051 30008 0R Jumper 0603
4522 4822 051 30008 0R Jumper 0603
4523 4822 051 30008 0R Jumper 0603
4524 4822 051 30008 0R Jumper 0603
4525 4822 051 30008 0R Jumper 0603
4527 4822 051 30008 0R Jumper 0603
4528 4822 051 30008 0R Jumper 0603
4529 4822 051 30008 0R Jumper 0603
4530 4822 051 30008 0R Jumper 0603
4531 4822 051 30008 0R Jumper 0603
4532 4822 051 30008 0R Jumper 0603
4533 4822 051 30008 0R Jumper 0603
4534 4822 051 30008 0R Jumper 0603
4535 4822 051 30008 0R Jumper 0603
4537 4822 051 30008 0R Jumper 0603
4538 4822 051 30008 0R Jumper 0603
4539 4822 051 30008 0R Jumper 0603
4540 4822 051 30008 0R Jumper 0603
4541 4822 051 30008 0R Jumper 0603
4542 4822 051 30008 0R Jumper 0603
4543 4822 051 30008 0R Jumper 0603
4544 4822 051 30008 0R Jumper 0603
4545 4822 051 30008 0R Jumper 0603
4546 4822 051 30008 0R Jumper 0603
4548 4822 051 30008 0R Jumper 0603
4549 4822 051 30008 0R Jumper 0603
4550 4822 051 30008 0R Jumper 0603
4551 4822 051 30008 0R Jumper 0603
4552 4822 051 30008 0R Jumper 0603
4553 4822 051 30008 0R Jumper 0603
4554 4822 051 30008 0R Jumper 0603
4555 4822 051 30008 0R Jumper 0603
4556 4822 051 30008 0R Jumper 0603
4557 4822 051 30008 0R Jumper 0603
4558 4822 051 30008 0R Jumper 0603
4559 4822 051 30008 0R Jumper 0603
4560 4822 051 30008 0R Jumper 0603
4561 4822 051 30008 0R Jumper 0603
4562 4822 051 30008 0R Jumper 0603
4563 4822 051 30008 0R Jumper 0603
4564 4822 051 30008 0R Jumper 0603
4565 4822 051 30008 0R Jumper 0603
4566 4822 051 30008 0R Jumper 0603
4570 4822 051 30008 0R Jumper 0603
4571 4822 051 30008 0R Jumper 0603
4572 4822 051 30008 0R Jumper 0603
4573 4822 051 30008 0R Jumper 0603
4574 4822 051 30008 0R Jumper 0603
4575 4822 051 30008 0R Jumper 0603
4579 4822 051 30008 0R Jumper 0603
4585 4822 051 30008 0R Jumper 0603
4593 4822 051 30008 0R Jumper 0603
4598 4822 051 30008 0R Jumper 0603
4653 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5201 2422 536 00548 Coil 100uH 15%
5232 4822 157 10586 Coil 2,2uH 10%
5401 4822 157 10586 Coil 2,2uH 10%
5402 4822 157 70601 Coil 100uH 10%
5407 4822 157 10586 Coil 2,2uH 10%
DIODES
6101 9337 12920673 BZX79-C11
6123 9340 548 61115 BZX384-C12
6200 4822 130 11397 BAS316
6201 4822 130 11397 BAS316
6202 4822 130 10871 SBYV27-200
6204 4822 130 31878 1N4003G
6205 9322 128 70685 SS14
6223 4822 130 31878 1N4003G
6224 4822 130 34278 BZX79-B6V8
6225 4822 130 31878 1N4003G
6226 4822 130 34142 BZX79-B33
6227 4822 130 11397 BAS316
6228 4822 130 11397 BAS316
TRANSISTORS & INTEGRATED CIRCUITS
7100 5322 130 60159 BC847B
7101 4822 130 60373 BC857B
7130 9322 150 74668 TDA7468D
7131 4822 130 40959 BC547B
7132 4822 130 60373 BC857B
7133 4822 130 42804 BC817-25
7150 5322 130 60159 BC847B
7200 4822 130 42804 BC817-25
7204 4822 130 40995 BD438
only for Prod start up
9322 196 61687 BD242 running chang over
7205 4822 130 41246 BC327-25
7206 4822 130 40995 BD438
7207 3198 010 42310 BC847BW
7208 4822 130 40995 BD438
7209 3198 010 42310 BC847BW
7210 9322 188 75682 LM2576T-3.3
7211 3198 010 42310 BC847BW
7230 4822 209 31378 NJM4556MB
7231 4822 130 60373 BC857B
7232 5322 130 60159 BC847B
7233 5322 130 60159 BC847B
7250 4822 130 42804 BC817-25
7252 4822 130 60373 BC857B
7253 5322 130 60159 BC847B
7301 5322 130 60159 BC847B
7302 4822 130 60373 BC857B
7304 9322 150 74668 TDA7468D
7330 9322 150 74668 TDA7468D
7352 9337 148 20653 74HC4051D
7402 4822 209 17345 M62320FP
7405 5322 130 60159 BC847B
7406 5322 130 60159 BC847B
7421 5322 130 60159 BC847B
7422 5322 209 11102 HEF4052BT
7423 5322 130 60159 BC847B
7451 4822 130 42804 BC817-25
7452 4822 130 42804 BC817-25
Note: Only the parts mentioned in this list are normal service
spare parts.
