Philips P Series User Manual

43BDL3117P/50BDL3117P/55BDL3117P
28
H position
Moves the horizontal position of the
image left or right.
V position
Moves the vertical position of the image
up or down.
Auto adjust
Press “Set” to detect and adjust H position, V position, Clock,
Phase automatically.
NOTE: VGA input only.
Screen reset
Reset all settings in the Screen menu to factory preset values.
6.2.3. Audio
Audio
Screen
Conguration 1
Conguration 2
Option
Treble
Bass
Volume Minimum
Balance
Volume
Audio Out Volume
Volume Maximum
Mute
50
50
0
30
O
O
On
30
0
100
Audio source
Audio Reset
Speaker
Sync.Volume
Digital
Balance
Adjust to emphasize left or right audio output balance.
Treble
Adjust to increase or decrease higher-pitched sounds.
Bass
Adjust to increase or decrease lower-pitched sounds.
Volume
Adjust the volume.
Audio Out Volume
Adjust to increase or decrease the line out audio output
level.
Minimum volume ≤ Volume ≤ Maximum volume
NOTE: This function will be disabled when Audio Out Sync is
ON.
Volume Maximum
Adjust your own limitation for the maximum volume setting.
Volume Minimum
Adjust your own limitation for the minimum volume setting.
Mute
Turn the mute function on/o.
Speaker
Turn the internal speaker on/o.
NOTE: This function is only availavle when “Audio Out Sync”
is on.
Sync. Volume
Enable/disable audio out (line out) volume adjustability to
sync with internal speakers volume, but PD Internal speaker
sound will be forced to be mute.
Audio source
Select the audio input source.
Analog: audio from audio input.
Digital : audio from HDMI/DVI audio.
Displyport: audio from DP
Audio Reset
Reset all settings in the Audio menu to factory preset values.
6.2.4. Configuration1 menu
Panel Saving
RS232 routing
WOL
Switch on state
Last status
RS232
O
On
O
O
Boot On Source
Light Sensor
Power LED Light
Network Settings
Conguration1 Reset
Factory Reset
Human Sensor
Audio
Screen
Conguration 1
Conguration 2
Option
Switch on State
Select the display status when you connect the power cord
next time.
• {Power o} - The display will remain o when the power
cord is connected to a wall outlet.
• {Forced on} - The display will turn on when the power
cord is connected to a wall outlet.
• {Last status} - The display will return to the previous
power status (on/o/standby) when removing and
replacing the power cord.
Panel saving
Choose to enable the panel saving functions and thus reduce
the risk of “image persistence” or “ghost-imaging”.
• {Brightness} - Select {On} and the image brightness will be
reduced to an appropriate level. The Brightness setting in
the Picture menu will be unavailable when selected.
• {Pixel shift} - Select the time interval ({Auto} / {10 ~
900} Seconds / {O}) for the display to slightly expand
the image size and shift the position of pixels in four
directions (up, down, left, or right).
RS232 routing
Select the network control port.
Choose from: {RS232} / {LAN ->RS232}.
Boot on source
Select the source when booting up.
• Input: select input source when boot up.
• Play List: select playlist index for Media player source.
None: no playlist autoplay function depends on {OPTION}
-> { Autoplay}.
