65BDL3652T/75BDL3652T/86BDL3652T
69
How to setup the settings in the menu to
control all the monitors at the same time
and individually via RC?
Daisy chained by RS232 and no IR cable 1. The rst display sets as “Primary” on
OSD (Advanced option/IR control item),
others set as “Secondary”.
2. The setup OSD will show on top left
side of the display.(Toggle MENU will
show again if it disappear)
3. Default setting: ID NO: 0, GP NO: 0, this
setting can control all displays by IR.
The “+”, “-” can change “ID NO” to
control signal display by “Monitor ID”.
The “UP”, “DOWN” can change “GP NO”
to control multi-display by “Group ID”.
*The rst display is always controlled by
IR.
How is the RC working? Daisy chain: no connection of RS232 and
IR cable
No setting is required. Connect with IR
cables and control by IR.
*This may cause out-of-synchronizm
phenomenon. It is suggested to use the
above settings with RS-232 cable.
