2002 Jan 17 2
Philips Semiconductors Product specification
2 × 6 W stereo power amplifier TDA1517; TDA1517P
FEATURES
• Requires very few external components
• High output power
• Fixed gain
• Good ripple rejection
• Mute/standby switch
• AC and DC short-circuit safe to ground and V
P
• Thermally protected
• Reverse polarity safe
• Capability to handle high energy on outputs (V
P
=0V)
• No switch-on/switch-off plop
• Electrostatic discharge protection.
GENERAL DESCRIPTION
The TDA1517 is an integrated class-B dual output
amplifier in a plastic single in-line medium power package
with fin (SIL9MPF) and a plastic heat-dissipating dual
in-line package (HDIP18). The device is primarily
developed for multi-media applications.
QUICK REFERENCE DATA
ORDERING INFORMATION
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
V
P
supply voltage 6.0 14.4 18.0 V
I
ORM
repetitive peak output current −−2.5 A
I
q(tot)
total quiescent current − 40 80 mA
I
sb
standby current − 0.1 100 µA
I
sw
switch-on current −−40 µA
|Z
I
| input impedance 50 −−kΩ
P
o
output power R
L
=4Ω; THD = 0.5% − 5 − W
R
L
=4Ω; THD = 10% − 6 − W
SVRR supply voltage ripple rejection f
i
= 100 Hz to 10 kHz 48 −−dB
α
cs
channel separation 40 −−dB
G
v
closed loop voltage gain 19 20 21 dB
V
no(rms)
noise output voltage (RMS value) − 50 −µV
T
c
crystal temperature −−150 °C
TYPE
NUMBER
PACKAGE
NAME DESCRIPTION VERSION
TDA1517 SIL9MPF plastic single in-line medium power package with fin; 9 leads SOT110-1
TDA1517P HDIP18 plastic heat-dissipating dual in-line package; 18 leads SOT398-1
