Philips Semiconductors Product specification
2 × 6 W stereo power amplifier TDA1517; TDA1517P
DC CHARACTERISTICS
V
P
= 14.4 V; T
amb
=25°C; measured in Fig.6; unless otherwise specified.
Note
1. The circuit is DC adjusted at V
P
= 6 to 18 V and AC operating at V
P
= 8.5 to 18 V.
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
Supply
V
P
supply voltage note 1 6.0 14.4 18.0 V
I
q(tot)
total quiescent current − 40 80 mA
V
O
DC output voltage − 6.95 − V
Mute/standby switch
V
8
switch-on voltage level see Fig.5 8.5 −−V
Mute condition
V
O
output signal in mute position V
I(max)
=1V; f
i
=20Hzto15kHz −−2mV
Standby condition
I
sb
DC current in standby condition −−100 µA
V
sw
switch-on current − 12 40 µA
