Finally, adding a 50mΩ resistor between the output and the diode gave some more
improvement.
The total circuitry needed for optimum reliability in dual voice coil applications is shown in
fig.43.
(1)
Fig 42. Protection against positive pulses at the output.
Parasitic
Clift
Vsupply
Pgnd
SPEAKER
1N4007
Schottky
ROHM RSX301L
