Instructions for Use | Therapy Modes and Controls
Therapy Control Settings 28
Setting Name
Setting Range/Increment
• All circuits: 0-20 cmH
2
O
• Increments: 1 cmH
2
O
Breath Rate
Adult patient type: 0-80 BPM, 1BPM increments
Pediatric patient type: 0-60 BPM, 1BPM increments
Infant patient type: 0-40 BPM, 1 BPM increments
CPAP
Adult and pediatric patient types: 3-25 cmH
2
O, 1 cm H
2
O increments
Infant patient type: 3-15 cmH
2
O, 1 cm H
2
O increments
EPAP Min/Max
Adult and pediatric patient types: 3-25 cmH
2
O, 1 cm H
2
O increments
Infant patient type: 3-15 cmH
2
O, 1 cm H
2
O increments
FiO
2
21-100%, 1% increments
(21% = ambient condition, no control)
Flow Cycle Sensitivity
10-90%, 1% increments
Flow Pattern
Square: airflow is constant
Ramp: inspiration airflow starts high and decreases
Flow Trigger Sensitivity
0.5 (high sensitivity) to 9 L/min (low sensitivity)
Inspiratory Time
Adult patient type: 0.5-5.0 seconds, 0.1 second increments
Pediatric patient type: 0.3-2.0 seconds, 0.1 second increments
Infant patient type: 0.3-1.0 seconds, 0.1 second increments
IPAP
Adult patient type: 3-60 cmH
2
O, 1 cmH
2
O increments
Pediatric patient type: 3-45 cmH
2
O, 1 cmH
2
O increments
Infant patient type: 3-35 cmH
2
O, 1 cmH
2
O increments
Max Pressure
• 6-60 cmH
2
O, 1 cmH
2
O increments
PEEP
Adult patient type:
• Active circuit: 0-35 cmH
2
O
• Passive circuit: 3-25 cmH
2
O
•
Increments: 1 cmH
2
O
Pediatric patient type:
• Active circuit: 0-25 cmH
2
O
• Passive circuit: 3-25 cmH
2
O
• Increments: 1 cmH
2
O
Infant patient type:
• Active circuit: 0-15 cmH
2
O
• Passive circuit: 3-15 cmH
2
O
• Increments: 1 cmH
2
O
Pressure Control
Adult patient type:
• All circuits but passive: 0-60 cmH
2
O
• Passive circuit: 0-57 cmH
2
O
• Increments: 1 cmH
2
O
Pediatric patient type:
• All circuits: 0-30 cmH
2
O
•
Increments: 1 cmH
2
O
Infant patient type:
• All circuits: 0-20 cmH
2
O
•
Increments: 1 cmH
2
O
Pressure Support
Adult patient type:
• All circuits but passive: 0-60 cmH
2
O
• Passive circuit: 0-57 cmH
2
O
•
Increments: 1 cmH
2
O
Pediatric patient type:
• All circuits: 0-30 cmH
2
O
•
Increments: 1 cmH
2
O
Infant patient type:
• All circuits: 0-20 cmH
2
O
•
Increments: 1 cmH
2
O
PS Min/Max
• All circuits but passive: 0-60 cmH
2
O
• Passive circuit: 0-57 cmH
2
O
• Increments: 1 cmH
2
O
Rise Time
0 (faster) to 6 (slower)
Tidal Volume
Adult patient type:
70-1200 ml
Increment: 5 ml
