12. Technical Specifications
Specifications
Ventilation types and modes
• A/C-PC: Assist control (pressure control)
• A/C-VC: Assist control (volume control)
• CPAP: Continuous positive airway pressure
• PSV: Pressure support ventilation
• S/T: Spontaneous/timed ventilation
• SIMV-PC: Synchronized intermittent mandatory ventilation (pressure control) - mandatory breaths are
synchronized to a patient’s inspiratory efforts
• SIMV-VC: Synchronized intermittent mandatory ventilation (volume control) - mandatory breaths are
synchronized to a patient’s inspiratory efforts
Controls
Delivered tidal volume
35 – 1,200 ml
Breath rate
0 – 80 BPM with a resolution of 1 BPM
PEEP
0 – 35 cm H
2
0 for active exhaust circuits
3 – 25 cm H
2
0 for passive circuits
EPAP/CPAP
3 – 25 cm H
2
0
IPAP
3 – 60 cm H
2
0
Pressure support/pressure control
0 – 60 cm H
2
0, Patient pressure limited to 60cmH
2
O
Inspiratory time
0.3 – 5.0s, constrained to prohibit an inverse I:E ratio
Rise time
0, 1, 2, 3, 4, 5, 6
Triggering and cycling
AutoTrak, Sensitive AutoTrak, and Flow Trigger
Flow trigger sensitivity
0.5 – 9 l/min
Flow cycle
10% – 90% of peak flow
Flow pattern
Square, Ramp
FiO
2
21% – 100% when available
Measured and Displayed Patient Parameters
Tidal volume (Vti or Vte)
0 to 2000 ml with a resolution of 1 ml
Minute ventilation (MinVent)
0 to 30 l/min with a resolution of 0.1 l/min
Leak
0 to 200 l/min with a resolution of 0.1 l/min
Respiratory rate (RR)
0 to 90 BPM with a resolution of 1 BPM
Peak inspiratory flow
0 to 200 l/min with a resolution of 0.1 l/min
Peak inspiratory pressure (PIP)
0 to 90 cmH
2
O with a resolution of 0.1 cmH
2
O
Mean airway pressure
0 to 90 cmH
2
O with a resolution of 0.1 cmH
2
O
Percentage spontaneous triggered
breaths
0 to 100% with a resolution of 1%
I:E ratio
9.9:1 to 1:9.9
Dynamic compliance
0.5 to 200 ml/cmH
2
O with a resolution of 0.1 ml/cmH
2
O
Dynamic resistance
2 to 200 cmH
2
O/l/sec with a resolution of 0.1 cmH
2
O/l/sec
Dynamic plateau pressure
0 to 90 cmH
2
O with a resolution of 0.1 cmH
2
O
Auto-PEEP
0 to 90 cmH
2
O with a resolution of 0.1 cmH
2
O
FiO
2
21% to 100% with a resolution of 1%
SpO
2
with pulse oximeter accessory
0 to 100% with a resolution of 1%
Pulse rate with pulse oximeter accessory
25 to 240 beats per minute with a resolution of 1 beat per minute
etCO
2
with end tidal CO
2
accessory
0 to 150 mmHg with a resolution of 1 mmHg
