OPERATION : DMX OPERATION
3
02.9690.0001 A 15 April 2010 23
22 Beam Time 0 - 255 0 - 100% 255
Allows for luminaire timing of zoom. Profile
should default to DMX 255 for smoothest con-
sole fade times.
23 Control 0 - 255 0 - 100%
Used to set different modes, parameters, and
functions of the VLX Wash. Set control channel
value for desired action. Hold value for at least 3
seconds. Set control channel value to 0 without
any scaling.
Default Setting on Console = DMX 0
Reset All to Defaults** = DMX 5 - 7
Quiet Mode† = DMX 11 - 13
Level Light Mode† = DMX 14 -16
Constant Fans Mode† = DMX 17 - 19
Normal Mode† = DMX 20 - 22
Dimmer Curve LINEAR† = DMX 31 - 32
Dimmer Curve SQUARE LAW† = DMX 34 - 35
Full Luminaire Reset = DMX 81 - 87
Color Calibration OFF† = DMX 116 - 117
Color Calibration ON† = DMX 118 - 120
Fixture Sleep = DMX 245 - 249
Fixture Wake Up* = DMX 250 - 255
Notes
:
*Please note that Fixture Wake Up will com-
pletely re-calibrate the fixture.
** When resetting to defaults, the following will
be enabled on the luminaire:
• Normal Mode
• Dimmer Curve SQUARE LAW
• Color Calibration ON
† These settings require the Command Lock in
Menu to be set to OFF in order to change on
Control Channel. Resetting to defaults will turn
Command Lock OFF.
Table 3-1: VLX™ Wash Luminaire Mapping Mode 1
