VARI❋LITE® - VLX™ WASH LUMINAIRE USER’S MANUAL
24 15 April 2010 02.9690.0001 A
Control Channel Functions
Used to set different modes, parameters, and functions of the VLX™ Wash Luminaire via the control
console. Set control channel value for desired action. Hold value for at least 3 seconds.
Set control channel value to 0 without any scaling. Discrete values must be used; not manual controls
such as faders or encoders (see chart below for values).
To use control channel functions:
Step 1. Select an action to be sent.
Step 2. Set control channel value for desired action (for example, 84 for reset). Hold value for at
least 3 seconds.
Step 3. Set control channel value to zero. (This must occur without any scaling values. Action will
be voided if other values are detected between action value and zero.)
Note: A numerical keypad is required for sending values. An encoder or fader does not allow for a
quick value change, which is required to effect the control functions. However, the encoders on some
consoles include discreet value capability.
Table 3-2: Control Channel Functions
DMX Channel Control Channel Function Control Channel DMX Value
23
Default Setting on Console 0
Reset All to Defaults**
5 - 7
Quiet Mode† 11 - 13
Level Light Mode† 14 - 16
Constant Fans Mode
† 17 - 19
Normal Mode
† 20 - 22
Dimmer Curve LINEAR† 31 - 32
Dimmer Curve SQUARE LAW
† 34 - 35
Full Luminaire Reset 81 - 87
Color Calibration OFF
† 116 - 117
Color Calibration ON
† 118 - 120
Fixture Sleep 245 - 249
Fixture Wake Up* 250 - 255
Notes:
*Please note that Fixture Wake Up will completely re-calibrate the fixture.
** When resetting to defaults, the following will be enabled on the luminaire:
• Normal Mode
• Dimmer Curve SQUARE LAW
• Color Calibration ON
† These settings require the Command Lock in Menu to be set to OFF in order to change on Control Chan-
nel. Resetting to defaults will turn Command Lock OFF.
