VARI❋LITE® - VLX™ WASH LUMINAIRE USER’S MANUAL
28 15 April 2010 02.9690.0001 A
Intensity Time Control
Beam Control
Strobe
Beam Spreader
Table 3-9: DMX Map for Intensity Time Control
DMX Channel % Value
DMX
Value
Default - These values
are recommended
console default values
Action
19 0 - 100 0 - 255 255
Allows for luminaire timing of
intensity. Profile should
default to DMX 255 for
smoothest console fade
times.
Table 3-10: DMX Map for Strobe
DMX Channel % Value DMX Value
Default - These values
are recommended
console default values
Action
18 0 - 100
0-2
0
Open
3-5 Closed
6-7 Slow Random
8-10 Medium Random
11-12 Fast Random
13 - 127* Strobe Range
128 - 129 Pulse + Slow Random
130 - 131 Pulse + Medium Random
132 - 133 Pulse + Fast Random
134 - 191 Pulse + Range
192 - 193 Pulse - Slow Random
194 - 195 Pulse - Medium Random
196 - 197 Pulse - Fast Random
198 - 255 Pulse - Range
Note: * = 13 (slowest) to 127 (fastest)
Table 3-11: DMX Map for Beam Spreader
DMX Channel % Value
DMX
Value
Default - These values
are recommended
console default values
Action
17 0 - 100 0 - 255 0
Controls Beam Angle from 23
degrees (DMX 0) to 58
degrees (DMX 255)
