MENU SYSTEM : MENU FUNCTIONS
4
02.9690.0001 A 15 April 2010 49
DMX
DMX Data
DATA Chan XXX DMX Channel XXXX Value 0 - 255
Pan/Tilt
Pan and Tilt
Options
Swap Swap Pan & Tilt ON
OFF
Inv Pan
Invert Pan ON
OFF
Inv Tilt
Invert Tilt ON
OFF
Fixture Status Status/Error Display Scrolls error messages or
displays
OK
Re-Calibrate Recalibrate
fixture
OK? Asks (confirms) to execute
recalibration of fixture
Version
Version MM/DD/YY (Page 1) HH:MM (Page 2)
Fixt Hrs Fixture Hours XXXX # Number of Fixture Hours
Download
Download
Software
OK? Asks (confirms) to
download software in fixture
Manual
Manual
Commands
(Disabled when
DMX Present.)
Pan* XXXXX DMX Value
Tilt * XXXXX DMX Value
Dimmer* XXXXX DMX Value
Red* XXXXX DMX Value
Blue* XXXXX DMX Value
Green* XXXXX DMX Value
White* XXXXX DMX Value
Beam Sprdr XXX DMX Value
Strobe XXX DMX Value
Table 4-1: VLX Wash Menu System Chart
1st Level 2nd Level 3rd Level 4th Level 5thLevel
Menu system description continued on next page.
