Philips VR620CAT - Connecting Without Cable Box;DBS (Continued); Connect VCR to TV via Coaxial Cable; Connect Power Cords; Set VCR CH3;CH4 Output Channel

CH 4
or
CH 3
CH3 / CH4
Switch
CH3 CH4
75
ANT /
CABLE
75Ω
ANT /
CABLE
RF coaxial cable
3
Connect the supplied black RF coaxial cable to the OUT Jack on the back of
the VCR and to the ANTENNA IN Jack on the TV. (You may use either a snap-on
type (supplied) or screw-on type of coaxial cable, whichever you prefer.)
5
Set the CH3/CH4 switch on the back of the VCR to CH3 or CH4, whichever
channel is not used or least used in your area. Set the TV to the same channel. For
example, when playing a tape, if the CH3/CH4 switch is set to CH3, the TV should be on
channel 03.
Hookups Without a Cable Box/Direct Broadcast System (cont’d) 7
ANTENNA IN Jack
(on back of TV)
example only
4
Plug in the power cords of the TV and the VCR.
6
You are ready to turn on the VCR. Please go to page 11 before turning on the
VCR.
