4 Use a coin to turn the battery cover in the ‘CLOSE’ direction until
the ‘I’ mark on the cover is aligned with the ‘I’ mark on the water
purier (Fig. 5).
Note: Make sure you align the ‘I’ marks properly, otherwise water may leak
into the battery compartment.
When the battery is properly inserted, the LCD display performs a
self-check for approx. 9 seconds. Then the display goes off again.
Before installation
The screw thread of the tap is sharp.
Before you install the water purier, make sure all tap-mounting
adapters you require are present.
The tap must have a diameter of 13mm-25mm.
Determine what type of tap you have and select the appropriate
adapter.
The adapters supplied make the water purier suitable for almost
any kitchen tap. However, the water purier may not t some
uncommon types of taps.
The tap water pressure has to be between 0.7kgf/cm² (7 metres of
water column/70kPa) and 3.5kgf/cm² (35 metres of water column/
350kPa). If you use the water purier at a water pressure outside this
range, either the ltered water ow will be extremely low or the
water purier will get damaged.
Installation A-type adapter
For taps with a round spout with a diameter of 16mm, 17.5mm or
19mm (Fig. 6).
1 Remove the attachment nut and the adapter from the water
purier housing (Fig. 7).
2 Pass the attachment nut over the tap spout (Fig. 8).
3 Place the matching adapter (A-type) over the tip of the spout. The
16mm adapter is packed with the water purier. If necessary,
replace it with the 17.5mm adapter or 19mm adapter to t the
diameter of your tap (Fig. 9).
,
-
-
-
-
-
-
ENGLISH10
