Phoenix 1200 - Phoenix 1200 Desiccant Dehumidifier Specifications; Power Specifications; Water Removal Capacity; Blower Airflow Rates

2 www.UsePhoenix.com • sales@UsePhoenix.comToll-Free 1-800-533-7533
1 Specifications
Part No. 4028000
Power 230voltsinglephaseunit
 withuserselectable25or40ampdraw
Water 344pints/day(43Gallons)
Removal @AHAM(80°F,60%)
Blower 900CFMProcessAirow
 300CFMReactAirow
Operating -10ºFto140ºF
Range
Duct Process/ReactInlet:12”exduct(optional)
Options ProcessOutlet:8”exductorlayatx2
 ReactivationOutlet:8”exduct(required)
Warranty 1yearPartsandService
Dimensions
 Machine
Width 26.5”
Height 35”
Depth 45”
Weight 265lbs

Popular Accessories And Replacement Parts
4020550 24”x12”x2”PleatedMediaMERV-7
4024750 12”x25’FlexDuct
4024935 10”x250’Lay-atDuct
4024440 Kestrel3000Multi-Meter
2 Operation
Thefunctionofthedehumidieristoremovemoisture(in
thevaporstate)fromanairstream.Thisisaccomplished
byexposingtheairtoanadsorbingmedia(desiccant)in
asealedairstream(process).Afterthedesiccanthas
adsorbedmoisture,itisexposedtoasecondairstream
atanelevatedtemperature(reactivation).Thiscauses
themoisturetobedrivenoutofthedesiccantpreparingit
formoremoistureadsorption.Thisprocessisdoneona
continuousbasis,providingaconstantdryingprocess.
Thetwoairstreams(processandreactivation)areseparated
byseals,whichcontactthedesiccantmedia.Figure“A”
illustratestherelationshipofthesealsandairowpattern.
Thedehumidierisdesignedwiththetwoairstreamsowing
inoppositedirections(counterow)therebymaximizingthe
energyefciencyoftheequipment.
Table of Contents
Introduction......................................................................... 1
1. Specifications................................................................ 2
2. Operation......................................................................2
3. Installation Instructions..................................................3
 3.1Inspection...............................................................3
 3.2PlacingTheMachine................................................ 3
 3.3Electrical.................................................................3
 3.4DuctWork...............................................................3
4. Operating Instructions.................................................... 3
 4.1Airow....................................................................3
 4.2DesiccantWheelRotation........................................ 3
5. Start-Up........................................................................ 3
 5.1ManualOperation....................................................3
 5.2AutomaticOperation................................................ 3
 5.3Make-UpAirVent..................................................... 4
6. Controls........................................................................4
 6.1ControlSwitch......................................................... 4
 6.2High/LowSwitch.....................................................4
 6.3UnitRunLight.........................................................4
 6.4Humidistat.............................................................. 4
 6.5ElectricReactivationControls...................................4
7. Dehumidifier Maintenance Instructions............................4
 7.1GeneralMaintenance...............................................4
 7.2Cabinet................................................................... 4
 7.3Filter....................................................................... 4
 7.4FanandMotor......................................................... 4
8. Drive Motor................................................................... 5
 8.1RotorDriveBelt.......................................................5
 8.2Seals......................................................................5
 8.3DesiccantMedia......................................................5
9. Dehumidifier Service Instructions....................................5
 9.1RemovingDesiccantRotor........................................5
 9.2ChangingSeals.......................................................5
 9.3InstallingSeals........................................................5
 9.4Troubleshooting....................................................... 6
10. Service Parts.................................................................7
11. Wiring Diagram.............................................................8
Warranty.......................................................................9
SerialNo._________________________________________
PurchaseDate_________/_________/_________
Dealer’sName_____________________________________
Read the operation and maintenance instructions carefully before
using this unit. Proper adherence to these instructions is essential
to obtain maximum benefit from your Phoenix 1200 dehumidifier.
•ItisdesignedtobeusedINDOORS ONLY.
•Ifusedinawetarea,plugitintoaGROUND FAULT
INTERRUPTER.
•DO NOTusethePhoenix1200asabenchortable.
•Itmustalwaysbeusedintheuprightposition.
