PG.50
AUGER DRIVE ASSY
1
2
3 4
6
3
5
7
8
9
10
11
12
13
12
14
17
18
21
20
15
19
18
17
16
5
2 REQ
2 REQ
2 REQ
2 REQ
22
23
DRIVE ASSY,AUGER,PHX-200-001
QTY
1ELBOW,3/8T X 1/4NPT50057-6281
1 50126-002 LUBRICATOR 2
-
50060-1312 FLATWASHER, 3/8" 3
1 50053-001 VALVE,POPPET,1/4"
2
4
50002-Z04 PIPE PLUG,1/4" 5
61 50016-002 ELBOW,5/32T X 1/8NPT
750040-0021 TEE, MALE RUN,1/4NPT
1 30088-001 RATCHET ASSY 8
9SCREW,FLT HD,1/4-20 X 1.75"10005-546
1030007-001
2
1 CLAMP,SUPPORT BLOCK
1
30008-001 SUPPORT BLOCK 11
12SCREW,FLT HD,1/4-20 X .75"10005-5404
13
14
15
16
BEARING & SPROCKET ASSY30006-0021
CHAIN ASSY30081-0011
SCREW,BTN HD,1/4-20 X .75"10007-I124
SCREW,SOC HD,1/4-20 X 1.75"10020-N281
3
10019-013 FLATWASHER,1/4" 17
18
LOCKNUT,1/4"
10009-0103
19
20
21
22
TENSION BLOCK30009-0011
FLATWASHER,THICK,1/4"
10027-0014
ADJUSTMENT PLATE
30012-0011
PLATE,AUGER DRIVE
30010-0011
23
BRACKET
30011-0011
