PG.57
SPECIFICATIONS
Dimensions: 18” x 20” x 47” (W x L x H)
(47cm x 51cm x 120cm)
Dry Weight: 165 lbs. (74.84 kg)
Hopper Capacity: Over 100 lbs. (45.5 kg) of pellets
Adjustable rate .5 lbs. to 5 lbs./ min.
(0.23 kg – 3.2 kg)
(dependent on pellet length & quality)
Supply Air Pressure Range: 70 psi – 250 psi (4.8 bar – 17.2 bar)
Air Consumption Range: 100 CFM – 450 CFM
Blast Pressure Range: 50 psi – 250 psi (2.8 bar – 17.2 bar)
Inlet Air Temperature: 140°F (60°C) maximum
Inlet Air Connection: 1” NPT
