PG.56
1 30091-001 1 THERMAL BREAK/ GASKET
2 50065-001 1 UNION, 5/32" TUBE
3 50065-003 1 UNION, 1/4" TUBE
4 10020-G12 8 SCREW, SOCKET HEAD, 6-32 X 3/4" LONG, SS
5 30057-001B 1 HANDLE, GUN
6 50022-2BK 18" TUBING, POLYURETHANE, 5/32", BLACK
7 50070-4BK 18" TUBING, POLYURETHANE, 1/4", BLACK
8 10020-I20 4 SCREW, SOCKET HEAD, 8-32 X 1 1/4" LONG, SS
9 10009-006 1 LOCKNUT, 8-32
10 50014-002 1 CONNECTOR, BARBED, 1/4"
11 30086-001 1 TRIGGER VALVE
12 10028-006 1 SPRING, LEVER RETURN
13 20001-001 1 TRIGGER LEVER
14 50014-001 1 CONNECTOR, BARBED, 5/32"
15 30052-001A 1 SHAFT, GUN
16 20008-001 2 BEARING, FLANGED
17 10029-034 1 RETAINING RING, SPIRAL
18 30067-001 A/R SHIM, GUN
19 30051-001 1 RETAINING COLLAR, GUN
20 20002-001 1 THRUST BEARING
21 10030-219 1 O-RING, DOUBLE SEAL
22 10020-I10 6 SCREW, SOCKET HEAD, 8-32 X 5/8" LONG, SS
23 30054-001 1 RETAINER, CAP
24 30053-001B 1 CAP, NOZZLE RETAINER
25 30055-001A 1 OUTLET, GUN
26 10007-H06 1 SCREW, BUTTON HEAD, 10-32 X 3/8"
27 30056-001A 1 GUN BODY
30083-001C ITEM LIST
A
= APPLY LOCTITE 242 TO THREADS
B
= COAT SEAL AND SHAFT EDGE WITH DC33
C
= PRESS BEARING INTO HOUSING
D
= PACK BEARING AND COAT WASHERS WITH DC-33
= ADD SHIMS TO REDUCE "IN/OUT" PLAY IN SHAFT
F
= PRESS BEARING INTO RETAINING COLLAR
E
