PG.54
AUGER SECTION
3
4
2
1
11
7
10
8
9
12
2 REQ
2 REQ
1 20004-005 Bearing,Auger Output 1
2 30004-001 Auger,PHX 1
3 10012-029 Standoff/Bearing Retainer 1
4 10007-I06 Screw,1/4 x 3/8 1
5 10019-013 Flatwasher,1/4" 1
6 10018-004 Lock washer, 1/4" 1
7 30035-001 Sprocket,Auger 1
8 30090-001 Key,Auger 1
9 10032-812 Screw,Bearing Retainer 2
10 10006-240 Set Screw,Sprocket 2
11 30005-001 Bearing,Auger Input 1
12 10019-017 Flatwasher,1/2" 1
13 30025-GRD CHAIN GUARD 1
To Next Page
