Phoenix PHX-200 - Vibrator Assembly

PG.51
VIBRATOR ASSY
10
1
2
3 4 5
6
7 8
7
9
Vibrator Assy, PHX-200-001
QTY
1VIBRATOR,IMPACT50063-0031
1 50060-131 PIPE NIPPLE, 1/4" CLOSE 2
-
50002-Z041 PIPE PLUG,1/4" 3
1 50016-002 ELBOW,5/32T X 1/8NPT
1
4
50053-001 VALVE,POPPET,1/4" 5
61 50040-002 TEE,MALE RUN,1/4NPT
750057-6282 ELBOW,3/8T X 1/4NPT
1 50060-133 PIPE NIPPLE,1/4NPT X 2" 8
9LUBRICATOR50126-002
1050059-002
1
1 MUFFLER
