Table of Contents
Introduction ............................................................................ 1
1. Safety Certications ....................................................... 2
2. Specications .................................................................2
3. Operation ........................................................................2
3.1 Transporting .............................................................. 2
3.2 Electrical Requirements ........................................... 3
3.3 Condensate Removal ............................................... 3
3.4 Ducting ......................................................................3
3.5 Defrost Cycle .............................................................3
3.6 Power Button ............................................................3
3.7 Purge Button .............................................................3
3.8 Hour Meter ................................................................3
3.9 Hours Button ............................................................3
3.10 Defrost Light ...........................................................3
4. Maintenance ...................................................................4
4.1 Air Filter ..................................................................... 4
4.2 Storage ......................................................................4
5. Service ............................................................................. 4
5.1 Technical Description ............................................... 4
5.2 Troubleshooting ........................................................ 5
5.3 Air Mover ...................................................................6
5.4 Thermistor .................................................................6
5.5 Condensate Pump .................................................... 6
5.6 Float Safety Switch ................................................... 6
6. Options & Accessories ...................................................6
7. Wiring Diagram ..............................................................7
8. Service Parts ................................................................... 8
Warranty .......................................................................... 9
1 Safety Certifications
The Phoenix R150 conforms to standards ANSI/UL 474 and
CSA C22.2 No.92.
2 Specifications
Part No. 4031250
Power 5.5 amps, 110-120 VAC, Grounded
Water 75 pints/day @ AHAM (80°F, 60%)
Removal 18 gallons/day maximum @ saturation
Process Air 150 CFM without external ducting
Refrigerant 1 lb, 4 oz. R410a
Charge
Operating 33°F to 110°F
Range
Filter 12” x 12” x 1” Pleated Media MERV-8
Duct
Options Outlet – 10” Lay-Flat
Warranty Five years;
1st year 100% of Parts and Labor
2nd-5th year 100% of Parts of sealed
refrigeration system.
Size 30” high x 20” wide x 17” deep
Weight 82 lbs
Patent 7,246,503
7,281,389
7,540,166
3 Operation
Place dehumidier inside structure, place condensate
hose into a drain, or a very large container, and turn on. To
decrease drying times, make sure all windows and doors
are closed to the outside and seal off the wet area from any
unaffected areas.
3.1 Transporting
The Phoenix R150 features a high-impact roto-molded
housing which protects the unit airways, and while loading
into vehicles. It is recommended the units are properly
secured for transport. The Phoenix R150 must always be
upright when transported by vehicle. It may be tipped onto its
handle and back for loading and moving by hand.
Read the operation and maintenance instructions
carefully before using this unit. Proper adherence to these
instructions is essential to obtain maximum benet from
your Phoenix R150 dehumidier.
• It is designed to be used INDOORS ONLY.
• If used in a wet area, plug it into a GROUND FAULT
INTERRUPTER.
• DO NOT use the Phoenix R150 as a bench or table.
• It must always be used in the upright position.
