9DFX2000
English
SPECIFICATIONS
ANALOG INPUTS
Connectors XLR and 1/4” TRS
Type RF ltered, servo-balanced input stage
Impedance 24 kΩ balanced
Nominal Operating Level -10 dBV or +4 dBu (selectable)
Max. Input Level +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level
ANALOG OUTPUTS
Connectors XLR and 1/4” TRS
Type Electronically servo-balanced output stage
Impedance 200 Ω balanced
Max. Output Level +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level
SYSTEM SPECIFICATIONS
Bandwidth 20 Hz to 20 kHz, +/- 3 dB
SNR 91 dB, unweighted, 20 Hz to 20 kHz
THD 0.018 % typ. @ +4 dBu, 1 kHz, 0 dBu input, gain 1
Crosstalk < -76 dB
MIDI INTERFACE
Type 5-pin DIN-socket IN / OUT or THRU
DIGITAL PROCESSING
Converters 24-bit Sigma-Delta, 128-times oversampling
Sampling Rate 44.1 kHz
DISPLAY
Type 4-digit 14 segment alpha-numeric LED-Display
POWER SUPPLY
Mains Voltages
USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
General Export Model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
Fuse
100 - 120 V ~: T500 mA H
200 - 240 V ~: T500 mA H
Power Consumption 15 Watts max.
Mains Connection Standard IEC receptacle
PHYSICAL
Dimensions (HxWxD) 483 x 44 x 217 mm (19” x 1.7” x 8.5”)
Net Weight 2.1 kg (4.63 lbs)
