13SONIC STATION 22 / SONIC STATION 32
Frequency Response (Mic input to any
output)
20Hz ~ 60KHz +0/-1 dB +0/-1 dB
20Hz ~ 100KHz +0/-3 dB +0/-3 dB
Crosstalk (1KHz @ 0dBu, 20Hz to
20KHz bandwidth, channel in to main
L/R outputs)
Channel fader down, other channels at
unity
<-90 dB <-90 dB
Noise (20Hz~20KHz; measured at
main output, Channels 1-4 unit gain;
EQ at; all channels on main mix;
channels 1/3 as far left as possible,
channels 2/4 as far right as possible.
Reference=+6dBu)
Master @ unity, channel fader down -86.5 dBu -86.5 dBu
Master @ unity, channel fader @ unity -84 dBu -84 dBu
S/N ratio, ref to +4 >90 dB >90 dB
Microphone Preamp E.I.N. (150 ohms
terminated, max gain)
<-129.5 dBm <-129.5 dBm
THD (Any output, 1KHz @ +14dBu, 20Hz
to 20KHz, channel inputs)
<0.005% <0.005%
CMRR (1 KHz @ -60dBu, Gain at
maximum)
80dB 80dB
Maximum Level
Mic Preamp Input +10dBu +10dBu
All Other Input +22dBu +22dBu
Unbalanced Output +22dBu +22dBu
Balanced Output +28dBu +28dBu
Impedance
Mic Preamp Input 2 K ohms 2 K ohms
All Other Input (except insert) 10 K ohms 10 K ohms
RCA 2T Output 1.1 K ohms 1.1 K ohms
Outputs 200 ohms 200 ohms
Equalization 3-band, +/-15dB 3-band, +/-15dB
Low EQ 80Hz 80Hz
Mid EQ (mono channels) 100-8k Hz, sweepable 100-8k Hz, sweepable
Mid EQ (stereo channels) 2.5k Hz 2.5k Hz
Hi EQ 12 kHz 12 kHz
Low cut lter 75 Hz (-18 dB/oct) 75 Hz (-18 dB/oct)
Power consumption 65 watts 70 watts
Power Requirement
(depends on region)
100~120V AC, 220~240V AC, 50/60Hz 100~120V AC, 220~240V AC, 50/60Hz
Net Weight (without adapter) 15.5 kg (34.14 lbs) 18 kg (39.65 lbs)
Dimensions (WxHxD) 859x102.79x547.42 mm
(33.8”x4.05”x21.6”)
1155.5x102.79x547.42 mm
(45.5”x4.05”x21.6”)
