Phonic XP 3000 Service Manual

PHONIC CORPORATION
Page 11
XP3000/3000(B) S ERVICE MANUAL
POWER AMPLIFER PCB-PART LIST
POWER AMPLIFIER PCB-PART LIST
Ref. Phonic Part No. Specifications
IC201 160-00021-900-0 IC NJM5534D JRC
210-10090-001-0 TMP/SW US-602SXRFQC
CN14.17 211-10021-150-0 2P WAFER/S 5267 A2505
WV P=2.5MM 180DEGREE
CN15 211-10021-161-0 2P WAFER/S TJC3-2A
P=2.5MM 180DEGREE
CN6.10 211-10061-171-0 6P WAFER/S TJC3-6A
P=2.5mm
CN9 211-10093-000-0 9P WAFER/S 3.96MM
212-10023-440-0 2P WAFER/P 100MM
313-00000-000-0 TRANSISTOR WASHER
TO-220
Q1B.2B.3B.19B.20B.21B.210-213.
228-231
313-00010-000-0 WASHER TO-3P
379-12800-001-0 W.MIRE UL1015#14 100MM
BLK
379-12800-011-0 W.MIRE UL1015#14 100MM
BRN
379-12800-021-0 W.MIRE UL1015#14 100MM
RED
526-20052-011-0 HEAT SINK XP3000/3000B
265*80*27mm
552-20061-400-0 FIXED BRKT PIII2000/3000
135*26*1.9
552-20063-400-0 TRAN. FIXED PIII600/1000
66*26*1.9MM
FIX TRANSISTOR*4 590-43012-100-0 M/E PAN SCR. M3.0*12NI
FIX *32 590-43014-100-0 M/E PAN SCR M3.0*14 NI
FIX THERMAL RES*1 591-54008-100-0 T/P SET SCR. D4.0*8 NI
610-00300-501-0 PLA. WAS. D3.0*D7.0*0.5
NI
610-60300-501-0 PAN SPR. WAS D3.0*D7*0.5
NI
PANEL 610-60401-001-0 PAN SPR. WAS. D4*7.6*1.0
NI
R213.214.220.221.305.326.338 006-10002-420-0 MF RES. 100 F 0.25W M

Phonic XP 3000 Specifications

General

Amplifier Type	Professional Power Amplifier
Number of Channels	2
THD	<0.03%
Signal-to-Noise Ratio	>100dB
Input Impedance	20 kOhms Balanced, 10 kOhms Unbalanced
Cooling	Variable speed fan
Connectors Input	XLR and 1/4" TRS
Power Output	3000W
Input Sensitivity	0.775V / 1.0V / 1.4V
Frequency Response	20Hz - 20kHz
Protection	Short Circuit, Thermal, Overload, DC Fault
Connectors Output	Speakon, Binding Post
Damping Factor	>300
